Description
Templates facilitating the placement (pre-assembly) of commercial civil series
components on NF’ and Deep applications. Mounting on 2-position box.
Main features
• Made of machined, unpainted aluminium
• With spirit level for perfect horizontal alignment
• Mounting on round or square flush-mounting box (hole spacing 60 mm)
• Double template for mounting on flush-mounting box with device centre distance 71 mm
Order information
Code
Dimensions L x H x P [mm]
For use with
Package
EK-DPD-Q
87 x 90 x 8.7
Template for square plate
1 pcs.
EK-DPD-D
160 x 90 x 9.7
Template for double plate
Templates for installation
of civil series components
on ‘NF/Deep applications
WALL-MOUNT DEVICES
Square mounting support
(for devices not supplied by Ekinex)
WALL-MOUNT DEVICES
Description
Square rubber mounting support for mounting devices or components not supplied
by Ekinex.
Order information
Code
Dimensions L x H x P [mm]
For use with
Package
EK-TFC-1
69.5 x 69.5 x 2
devices not supplied by Ekinex
1 pcs..
Dimensions [mm]
69.50
2.00
69.50
TECHNICAL024EN
