PRODUCT SPECIFICATIONS
Characters in bold are used for codes and specifications
which are necessary to identify the product code to be specified
in the order.
Les caractères en gras sont utilisés pour les codes et spécifications
sont utilisés pour identifier le code produit à mentionner dans la
commande.
Color code
Gross Lumen
Package
Light color
LAYOUT
D A L I
SYMBOLS
MARKS
LIGHT COLOR CODES
ACCESSORIES CODES
IP
Suspension
Wall
Recessed Ceiling
Protection class
Protection class I = dust / P = water
Beam angle
Walk over fitting
Drive over fitting
Surface Temperature
Rotation
Reparable fixture
CRI Color Rendering Index
Dimmer included
Cable length
/DIM Dimmer
/ST
Satin diffuser
/DALI Dimmer
/TR
Transparent diffuser
/DIM Dimmer
/EM
Emergency
Fixture ready for installation on normally
inflammable surfaces
Converter not included
SELV fixture with remote transformer
Converter included
Fixture on Class II, with double
or reinforced insulation
Cable
Ceiling
Table
Track
Recessed Wall
Floor
/W
Natural White Led 4000K
/WW Warm white Led 3000K
/XW
Extra white Led 2700K
1st digit: protection against penetration
by solid bodies
0 No protection
1 Protected against solid matters (over 50mm)
2 Protected against solid matters (over 12mm)
3 Protected against solid matters (over 2,5mm)
4 Protected against solid matters (over 1mm)
5 Dust proof
6 Fully dust proof
2nd digit: protection against
penetration by water
0 No protection
1 Protected against drops of water
falling vertically
3 Rain proof fixture
4 Splash proof fixture
5 Water jet proof
6 Wave proof
7 Watertight immersion fixture
Cut Out
.......... Kg
T< .....°C
.......... Kg
T< .....°C
