123
Focus Trimless Base
Independant driver included in article and pricing
Trimless kit included
Non dim
2700K - Ra97 - 9.8W - 860lm
1421.AA.24.H27.XX
3000K - Ra97 - 9.8W - 918lm
1421.AA.24.H30.XX
4000K - Ra97 - 9.8W - 960lm
1421.AA.24.H40.XX
1-10V dim
2700K - Ra97 - 9.8W - 860lm
1421.AA.25.H27.XX
3000K - Ra97 - 9.8W - 918lm
1421.AA.25.H30.XX
4000K - Ra97 - 9.8W - 960lm
1421.AA.25.H40.XX
DALI dim
2700K - Ra97 - 9.8W - 860lm
1421.AA.26.H27.XX
3000K - Ra97 - 9.8W - 918lm
1421.AA.26.H30.XX
4000K - Ra97 - 9.8W - 960lm
1421.AA.26.H40.XX
Dim-to-warm - 9.2W - 732lm
1421.AA.26.DTW.XX
Mains dim
2700K - Ra97 - 9.8W - 860lm
1421.AA.27.H27.XX
3000K - Ra97 - 9.8W - 918lm
1421.AA.27.H30.XX
4000K - Ra97 - 9.8W - 960lm
1421.AA.27.H40.XX
Dim-to-warm - 9.2W - 732lm
1421.AA.27.DTW.XX
Push/Touch dim
2700K - Ra97 - 9.8W - 860lm
1421.AA.29.H27.XX
3000K - Ra97 - 9.8W - 918lm
1421.AA.29.H30.XX
4000K - Ra97 - 9.8W - 960lm
1421.AA.29.H40.XX
Focus Trimless Plus
Independant driver included in article and pricing
Trimless kit included
Non dim
2700K - Ra97 - 13W - 1304lm
1417.AA.24.H27.XX
3000K - Ra97 - 13W - 1368lm
1417.AA.24.H30.XX
4000K - Ra97 - 13W - 1446lm
1417.AA.24.H40.XX
1-10V dim
2700K - Ra97 - 13W - 1304lm
1417.AA.25.H27.XX
3000K - Ra97 - 13W - 1368lm
1417.AA.25.H30.XX
4000K - Ra97 - 13W - 1446lm
1417.AA.25.H40.XX
DALI dim
2700K - Ra97 - 13W - 1304lm
1417.AA.26.H27.XX
3000K - Ra97 - 13W - 1368lm
1417.AA.26.H30.XX
4000K - Ra97 - 13W - 1446lm
1417.AA.26.H40.XX
Mains dim
2700K - Ra97 - 13W - 1304lm
1417.AA.27.H27.XX
3000K - Ra97 - 13W - 1368lm
1417.AA.27.H30.XX
4000K - Ra97 - 13W - 1446lm
1417.AA.27.H40.XX
Push/Touch dim
2700K - Ra97 - 13W - 1304lm
1417.AA.29.H27.XX
3000K - Ra97 - 13W - 1368lm
1417.AA.29.H30.XX
4000K - Ra97 - 13W - 1446lm
1417.AA.29.H40.XX
01
15
18
07
03
25
16
36
40
More info see “Color info” p.421
Colors Standard
01 - White Matt Texture
18 - Grey Matt Texture
07 - Anthracite Matt Text.
03 - Black Matt Texture
25 - Smoked Brown Text.
36 - Bronze
Colors Special
15 - Corten
16 - Gold
40 - Champagne
0000.AA.00.CCC.XX
Available colors (see below)
Other RAL colors on request
Hxx: CRI 97 (standard)
9xx: CRI 90
Plus
24: 24° Reflector
28: 28° Reflector
44: 44° Reflector
Base
16: 16° Reflector
30: 30° Reflector
41: 41° Reflector
CRI97
