META.02 / TARA.LOGIC
BASIN | SHOWER | BATH | ACCESSORIES
PAGE 42
PAGE 44
PAGE 46
PAGE 48
34 460 626 +
28 015 626
Showerpipe with shower thermostat
• shower with fixed riser projection 541 mm
• overhead shower: rain flow
• rain shower Ø 300mm
• rain shower with anti-scale system
• max. rainshower flow 14 l/min
• hand shower: normal flow
• spray head Ø 100mm
• max. hand shower flow 15 l/min
• rotary diverter with volume control and shut-off function
• slide-on rosettes Ø 70 mm
• height of fittings up to rain shower (bottom edge) 1009mm
• height of fittings up to top edge of elbow 1150mm
• gauge 150 mm - 13 mm
• metal shower hose 1750mm with integrated anti-twist
protection
• 1/2" connection
• slide bar
• Pipe diameter 23.5 mm
polished chrome
1x 34 460 626-00
1x 28 015 626-00
chrome matt
1x 34 460 626-93
1x 28 015 626-93
matt black
1x 34 460 626-33
1x 28 015 626-33
34 442 626
Shower thermostat for wall mounting
• slide-on rosettes Ø 70 mm
• gauge 150 mm - 13 mm
• rotary diverter with volume control and shut-off function
• 3/8" shower outlet
• with volume control
Intrinsic protection against back flow.
polished chrome
34 442 626-00
chrome matt
34 442 626-93
matt black
34 442 626-33
36 020 626
Concealed single-lever mixer without diverter
• cover plate Ø 150 mm
polished chrome
36 020 626-00
chrome matt
36 020 626-93
matt black
36 020 626-33
Required miscellaneous
Concealed single-lever mixer
• min. recess depth 80 mm
• max. recess depth 105 mm
Concealed rough parts
35 070 970 90
Required miscellaneous
Concealed single-lever mixer with backflow
preventor
• min. recess depth 80 mm
• max. recess depth 105 mm
Concealed rough parts
35 071 970 90
36 120 626
Concealed single-lever mixer with diverter
• automatic diverter
• cover plate Ø 150 mm
polished chrome
36 120 626-00
chrome matt
36 120 626-93
matt black
36 120 626-33
Required miscellaneous
Concealed single-lever mixer
• min. recess depth 80 mm
• max. recess depth 105 mm
Concealed rough parts
35 070 970 90
Required miscellaneous
Concealed single-lever mixer with backflow
preventor
• recess depth 80mm
• max. recess depth 105 mm
Concealed rough parts
35 071 970 90
26 413 626 +
28 015 626
Shower set
• slide bar
• rosette Ø 55 mm
• Pipe diameter 18 mm
• gauge 800 mm
• metal shower hose 1750mm with integrated anti-twist
protection
• shower hose connector 3/8"
• spray head Ø 100mm
• max. flow 15 l/min
Intrinsic protection against back flow.
polished chrome
1x 26 413 626-00
1x 28 015 626-00
chrome matt
1x 26 413 626-93
1x 28 015 626-93
matt black
1x 26 413 626-33
1x 28 015 626-33
28 649 626
Rain shower with wall fixing
• 450 mm projection
• rain flow
• with anti-scale system
• rain shower Ø 220mm
• rosette Ø 60 mm
• 1/2" connection
• max. flow 8.6 l/min
polished chrome
28 649 626-00
chrome matt
28 649 626-93
matt black
28 649 626-33
