META.02 / TARA.LOGIC
BASIN | SHOWER | BATH | ACCESSORIES
PAGE 42
PAGE 44
PAGE 46
PAGE 48
33 501 626
Single-lever basin mixer with pop-up waste
• 126 mm projection
• fixed spout
• circular, air-enriched flow
• height of mixer 132 mm
• height up to aerator 45 mm
• hole diameter 35 mm
• 2x screw-in M 10 x 1 pressure hose, leak-tested
• max. flow 7 l/min
• lead-free
Only suitable for basins with an overflow.
polished chrome
33 501 626-00
chrome matt
33 501 626-93
matt black
33 501 626-33
Product alternative
Single-lever basin mixer without pop-up
waste
• without pop-up waste
polished chrome
33 526 626-00
chrome matt
33 526 626-93
matt black
33 526 626-33
33 502 626
GRANDE Single-lever basin mixer with pop-up waste
• 130 mm projection
• fixed spout
• circular, air-enriched flow
• height of mixer 142 mm
• height up to aerator 52 mm
• hole diameter 35 mm
• 2x screw-in M 10 x 1 pressure hose, leak-tested
• max. flow 7 l/min
• lead-free
Only suitable for basins with an overflow.
polished chrome
33 502 626-00
chrome matt
33 502 626-93
matt black
33 502 626-33
Product alternative
GRANDE Single-lever basin mixer without
pop-up waste
• without pop-up waste
polished chrome
33 522 626-00
chrome matt
33 522 626-93
matt black
33 522 626-33
36 810 626
Wall-mounted single-lever basin mixer without pop-up
waste
• 170 mm projection
• fixed spout
• circular, air-enriched flow
• hole diameter spout 37 mm
• hole diameter single-lever mixer 57 mm
• rosette for spout Ø 55mm
• rosette for mixer Ø 78mm
• max. flow 7 l/min
• lead-free
polished chrome
36 810 626-00
chrome matt
36 810 626-93
matt black
36 810 626-33
Required miscellaneous
Concealed wall-mounted single-lever mixer
mixer on right
• min. recess depth 80 mm
• max. recess depth 95 mm
Concealed rough parts
35 870 970 90
36 812 626
Wall-mounted single-lever basin mixer without pop-up
waste
• 200 mm projection
• fixed spout
• circular, air-enriched flow
• hole diameter spout 37 mm
• hole diameter single-lever mixer 57 mm
• rosette for spout Ø 55mm
• rosette for mixer Ø 78mm
• max. flow 7 l/min
• lead-free
polished chrome
36 812 626-00
chrome matt
36 812 626-93
matt black
36 812 626-33
Required miscellaneous
Concealed wall-mounted single-lever mixer
mixer on right
• min. recess depth 80 mm
• max. recess depth 95 mm
Concealed rough parts
35 870 970 90
33 515 626
Single-lever basin mixer with pop-up waste
• 156 mm projection
• pivotable spout 360°
• circular, air-enriched flow
• height of mixer 302 mm
• height up to aerator 191 mm
• hole diameter 35 mm
• 2x screw-in M 10 x 1 pressure hose, leak-tested
• max. flow 7 l/min
• lead-free
Only suitable for basins with an overflow.
polished chrome
33 515 626-00
chrome matt
33 515 626-93
matt black
33 515 626-33
Product alternative
Single-lever basin mixer without pop-up
waste
• without pop-up waste
polished chrome
33 520 626-00
chrome matt
33 520 626-93
matt black
33 520 626-33
33 500 626
Single-lever basin mixer with pop-up waste
• 173 mm projection
• pivotable spout 360°
• circular, air-enriched flow
• height of mixer 321 mm
• height up to aerator 201 mm
• hole diameter 35 mm
• 2x screw-in M 10 x 1 pressure hose, leak-tested
• max. flow 7 l/min
• lead-free
Only suitable for basins with an overflow.
polished chrome
33 500 626-00
chrome matt
33 500 626-93
matt black
33 500 626-33
Product alternative
Single-lever basin mixer without pop-up
waste
• without pop-up waste
polished chrome
33 505 626-00
chrome matt
33 505 626-93
matt black
33 505 626-33
