583
582
BINARIO TRIFASE
/ 2007
/ 2007
BINARIO TRIFASE
Compulsory accessories
Luminaires
DOT BINARIO
13W
120V - 60Hz
2700K / 3000K
CRI >97
Driver integrated
1-10V
Matt White - 2700K - 1-10V
1A2290303.27.03
Matt White - 3000K - 1-10V
1A2290303.30.03
Matt Black - 2700K - 1-10V
1A2290403.27.03
Matt Black - 3000K - 1-10V
1A2290403.30.03
Matt White/Polished Gold - 2700K - 1-10V
1A2293903.27.03
Matt White/Polished Gold - 3000K - 1-10V
1A2293903.30.03
Matt Black/Polished Gold - 2700K - 1-10V
1A2294903.27.03
Matt Black/Polished Gold - 3000K - 1-10V
1A2294903.30.03
SPOT BINARIO
21W
120V - 60Hz
Driver integrated
1-10V
LED Module not included
Matt White - 1-10V
1A0280303.00.03
Matt Black - 1-10V
1A0280403.00.03
Matt White/Polished Gold - 1-10V
1A0283903.00.03
Matt Black/Polished Gold - 1-10V
1A0284903.00.03
Compulsory accessories
Other accessories
Lens
Not included
Beam - 14°
2700K - CRI >97 - 983lm
DOT BINARIO
1A3090000.00.00
3000K - CRI >97 - 1038lm
Beam - 24°
2700K - CRI >97 - 943lm
DOT BINARIO
1A3100000.00.00
3000K - CRI >97 - 996lm
Beam - 36°
2700K - CRI >97 - 955lm
DOT BINARIO
1A3110000.00.00
3000K - CRI >97 - 1005lm
Beam - 50°
2700K - CRI >97 - 965lm
DOT BINARIO
1A3120000.00.00
3000K - CRI >97 - 1016lm
LED modules
DG111 LED Module
Not included
13,5W - 15° - 400mA DC
2700K - 1318lm - CRI >90
Energy Efficiency F - Dimmable
SPOT BINARIO
1A4700003.27.20
13,5W - 15° - 400mA DC
3000K - 1345lm - CRI >90
Energy Efficiency F - Dimmable
1A4700003.30.20
DG111 LED module
Not included
13,5W - 22° - 400mA DC
2700K - 1502lm - CRI >90
Energy Efficiency F - Dimmable
SPOT BINARIO
1A3890003.27.20
13,5W - 22° - 400mA DC
3000K - 1570lm - CRI >90
Energy Efficiency F - Dimmable
1A3890003.30.20
DG111 LED module
Not included
13,5W - 36° - 400mA DC
2700K - 1451lm - CRI >90
Energy Efficiency F - Dimmable
SPOT BINARIO
1A3900003.27.20
13,5W - 36° - 400mA DC
3000K - 1527lm - CRI >90
Energy Efficiency F - Dimmable
1A3900003.30.20
