445
444
Omar Carraglia - Davide Groppi / 2015
DOT R
DOT R
Omar Carraglia - Davide Groppi / 2015
Compulsory accessories
Drivers
Driver
Not included
220-240V(100-127V)
350mA/18W(15W)/IP20/PUSH - 1-10V
1Z0240870.350
Driver
Not included
120-277V
350mA/30W/IP20/TRIAC - 1-10V
1Z2020050.350
Other accessories
Lens
Not included
Beam - 14°
2700K - CRI >97 - 983lm
1A3090000.00.00
3000K - CRI >97 - 1038lm
Beam - 24°
2700K - CRI >97 - 943lm
1A3100000.00.00
3000K - CRI >97 - 996lm
Beam - 36°
2700K - CRI >97 - 955lm
1A3110000.00.00
3000K - CRI >97 - 1005lm
Beam - 50°
2700K - CRI >97 - 965lm
1A3120000.00.00
3000K - CRI >97 - 1016lm
Optional accessories
Other accessories
Accessory holder + Honeycomb louvre
Not included
1X0080400.01.00
Elliptical filter
Not included
Standard
Compulsory with 1X0080400.01.00
1X0080000.02.00
Blue filter
Not included
Standard
Compulsory with 1X0080400.01.00
1X0080000.03.00
Red filter
Not included
Standard
Compulsory with 1X0080400.01.00
1X0080000.04.00
Yellow filter
Not included
Standard
Compulsory with 1X0080400.01.00
1X0080000.05.00
Recessed / Direct / Indoor
Material
Metal
Finish
.03 Matt White
.04 Matt Black
.49 Matt Black/Polished Gold
Note
Recessed luminaire. Adjustable in all directions. Plasterboard hole:
1.57"x1.57". Minimum space for recessed installation: 2.36".
DOT R
13W
Max 350mA DC
2700K / 3000K
CRI >97
Driver not included
Matt White - 2700K
1A4770303.27.20
Matt White - 2700K
1A4770303.30.20
Matt Black - 2700K
1A4770403.27.20
Matt Black - 3000K
1A4770403.30.20
Matt Black/Polished Gold - 2700K
1A4774903.27.20
Matt Black/Polished Gold - 2700K
1A4774903.30.20
