313
312
DOT P
Omar Carraglia - Davide Groppi / 2015
Omar Carraglia - Davide Groppi / 2015
DOT P
Wall-Ceiling / Direct / Indoor
Material
Metal
Finish
.03 Matt White
.04 Matt Black
.49 Matt Black/Polished Gold
Note
Wall luminaire. Adjustable in all directions. DOT P 51: white wall back
plate for matt white and matt black finishes. Black wall back plate for
the matt black/polished gold finish. DOT P ENDLESS and DOT P ENDLESS
CASAMBI: luminaires dedicated to ENDLESS system (Max 48V DC -
Max 150W - Max 4A). They can be used, on the same circuit, with the
ENDLESS models. See page: ENDLESS.
DOT P
13,5W
120V - 60Hz
2700K / 3000K
CRI >97
Driver integrated
1-10V
Matt White - 2700K - 1-10V
1A2340303.27.03
Matt White - 3000K - 1-10V
1A2340303.30.03
Matt Black - 2700K - 1-10V
1A2340403.27.03
Matt Black - 3000K - 1-10V
1A2340403.30.03
Matt Black/Polished Gold - 2700K - 1-10V
1A2344903.27.03
Matt Black/Polished Gold - 3000K - 1-10V
1A2344903.30.03
DOT P 51
Max 10W - GU10
120V - 60Hz
ON/OFF
Bulb not included
Matt White - ON/OFF
1A2490303.00.00
Matt Black - ON/OFF
1A2490403.00.00
Matt Black/Polished Gold - ON/OFF
1A2494903.00.00
DOT P ENDLESS
ENDLESS version only
13W - 0,34A
48V DC
2700K / 3000K
CRI >97
Driver not included
See page ENDLESS
Matt White - 2700K
1A2340303.27.40
Matt White - 3000K
1A2340303.30.40
Matt Black - 2700K
1A2340403.27.40
Matt Black - 3000K
1A2340403.30.40
Matt Black/Polished Gold - 2700K
1A2344903.27.40
Matt Black/Polished Gold - 3000K
1A2344903.30.40
DOT P ENDLESS CASAMBI
ENDLESS version only
15,5W - 0,4A
48V DC
2700K / 3000K
CRI >97
Driver not included
See page ENDLESS
Matt White - 2700K
1A2340303.27.41
Matt White - 3000K
1A2340303.30.41
Matt Black - 2700K
1A2340403.27.41
Matt Black - 3000K
1A2340403.30.41
Matt Black/Polished Gold - 2700K
1A2344903.27.41
Matt Black/Polished Gold - 3000K
1A2344903.30.41
