169
168
Davide Groppi / 2023
LOUIS XIV
LOUIS XIV
Davide Groppi / 2023
LOUIS XIV 2
Remote driver version
15W
Max 250mA DC
2700K - Up 890lm - Down 210lm /
3000K - Up 936lm - Down 235lm
CRI >90
Down UGR <19
Driver not included
2 Drivers required
Polished Gold - 2700K
1A4361900.27.20
Polished Gold - 3000K
1A4361900.30.20
Compulsory accessories / Accessori obbligatori
Drivers / Alimentatori
Driver for uplight emission / Alimentatore per emissione upligh
Not included
220-240V
250mA/12,5W/IP20/TRIAC/IGBT
LOUIS XIV 2
1Z0241280
Driver for downlight emission / Alimentatore per emissione downlight
Not included
220-240V
250mA/4,2W/IP20/TRIAC/IGBT
LOUIS XIV 2
1Z2320010
Driver / Alimentatore
Not included
220-240V(110-127V)
250mA/13,5W(13,5W)/IP20/DALI - PUSH
- 1-10V
LOUIS XIV 2
1Z0241270.250
Optional accessories / Accessori opzionali
Suspension kits / Kit di sospensione
Recessed suspension kit for 12,5 mm plasterboard / Kit di sospensione da incasso per cartongesso 12,5 mm
Not included
Matt White
For elettrical cables - 1 Piece
Plasterboard cut-out Ø 44 mm
Minimum space for mounting 70 mm
LOUIS XIV 2
1X0000300.05.00
Matt Black
For elettrical cables - 1 Piece
Plasterboard cut-out Ø 44 mm
Minimum space for mounting 70 mm
LOUIS XIV 2
1X0000400.05.00
Suspension / Direct-Indirect / Indoor
Material
Glass - Metal
Finish
.19 Polished Gold
Note
Suspension luminaire. Seventy-five crystal drops and two birds.
Natural brass branches. Structure with polished gold finish. Matt white
rose. Dual emission and on/off. White cable. LOUIS XIV 2: version with
power cable only and without rose.
Apparecchio illuminante a sospensione. Settantacinque gocce in cristallo
e due uccellini. Rami in ottone naturale. Struttura con finitura oro lucido.
Rosone bianco opaco. Doppia emissione ed accensione. Cavo bianco.
LOUIS XIV 2: versione con solo il cavo di alimentazione e senza rosone.
LOUIS XIV 1
Ceiling driver version
16,5W
110-240V - 50/60Hz
2700K - Up 890lm - Down 210lm /
3000K - Up 936lm - Down 235lm
CRI >90
Down UGR <19
Driver integrated
TRIAC/IGBT
Polished Gold - 2700K - TRIAC/IGBT
1A4361900.27.02
Polished Gold - 3000K - TRIAC/IGBT
1A4361900.30.02
LOUIS XIV 1
Ceiling driver version
16,5W
110-240V - 50/60Hz
2700K - Up 890lm - Down 210lm /
3000K - Up 936lm - Down 235lm
CRI >90
Down UGR <19
Driver integrated
DALI - PUSH - 1-10V
Polished Gold - 2700K - DALI - PUSH - 1-10V
1A4361900.27.07
Polished Gold - 3000K - DALI - PUSH - 1-10V
1A4361900.30.07
+
