PUNTO
PUNTO
/ 2004
Recessed / Direct / Indoor
Material
Metal
Finish
.03 Matt White
.04 Matt Black
Note
Recessed luminaire. Adjustable in all directions. Plasterboard hole:
133x148 mm. Minimum space for recessed installation: 180 mm.
Apparecchio illuminante da incasso. Orientabile in tutte le direzioni.
Foro del cartongesso: 133x148 mm. Spazio minimo per incasso: 180 mm.
PUNTO
Max 21W
Max 500mA DC
Driver not included
LED module not included
Matt White
1A1100300.00.20
Matt Black
1A1100400.00.20
Compulsory accessories / Accessori obbligatori
Installation kits / Kit d'installazione
Plasterboard frame 12,5 mm / Cornice per cartongesso 12,5 mm
Not included
Matt White
Cut-out 133x148 mm
Minimum space for mounting 180 mm
1A3510300.00.00
Matt Black
Cut-out 133x148 mm
Minimum space for mounting 180 mm
1A3510400.00.00
LED modules / Moduli LED
DG111 LED module / Modulo LED DG111
Not included
16,7W - 15° - 500mA DC
2700K - 1648lm - CRI >90
Energy Efficiency F - Dimmable
1A4700000.27.20
16,7W - 15° - 500mA DC
3000K - 1682lm - CRI >90
Energy Efficiency F - Dimmable
1A4700000.30.20
DG111 LED module / Modulo LED DG111
Not included
16,7W - 22° - 500mA DC
2700K - 1859lm - CRI >90
Energy Efficiency F - Dimmable
1A3890000.27.20
16,7W - 22° - 500mA DC
3000K - 1945lm - CRI >90
Energy Efficiency F - Dimmable
1A3890000.30.20
DG111 LED module / Modulo LED DG111
Not included
16,7W - 36° - 500mA DC
2700K - 1808lm - CRI >90
Energy Efficiency F - Dimmable
1A3900000.27.20
16,7W - 36° - 500mA DC
3000K - 1890lm - CRI >90
Energy Efficiency F - Dimmable
1A3900000.30.20
Drivers / Alimentatori
Driver / Alimentatore
Not included
220-240V(100-127V)
500mA/20W(15W)/IP20/DALI
1Z0241180.500
Driver / Alimentatore
Not included
220-240V(100-127V)
500mA/20W(15W)/IP20/PUSH
1Z0240840.500
Driver / Alimentatore
Not included
220-240V
500mA/20W/IP20/TRIAC/IGBT
1Z0240850.500
