MINI 51
MINI 51
/ 2016
Compulsory accessories / Accessori obbligatori
Installation kits / Kit d'installazione
Plasterboard frame 12,5 mm / Cornice per cartongesso 12,5 mm
Not included
Matt White
Cut-out 104x104 mm
Minimum space for mounting 130 mm
1A3500300.00.00
Matt Black
Cut-out 104x104 mm
Minimum space for mounting 130 mm
1A3500400.00.00
Optional accessories / Accessori opzionali
Bulbs / Lampadine
LED - GU10 - PAR16
Not included
220-240V - 5,5W - 25°
3000K - 375lm - CRI >97
Energy Efficiency G - Dimmable
1Y0330500
LED SORAA - GU10 - MR16
Not included
230V - 7,5W - 10°
2700K - 390lm - CRI >95
Energy Efficiency G - Dimmable
1Y1580210
LED SORAA - GU10 - MR16
Not included
230V - 7,5W - 10°
3000K - 410lm - CRI >95
Energy Efficiency G - Dimmable
1Y1580010
Other accessories / Altri accessori
Darklight
Not included
LED SORAA - GU10 - MR16
1Y1580040
25° beam filter / Filtro fascio 25°
Not included
LED SORAA - GU10 - MR16
1Y1580020
36° beam filter / Filtro fascio 36°
Not included
LED SORAA - GU10 - MR16
1Y1580030
Recessed / Direct / Indoor
Material
Metal
Finish
.03 Matt White
.04 Matt Black
Note
Recessed luminaire. Adjustable in all directions. Plasterboard hole:
104x104 mm. Minimum space for recessed installation: 130 mm.
Apparecchio illuminante da incasso. Orientabile in tutte le direzioni.
Foro del cartongesso: 104x104 mm. Spazio minimo per incasso: 130 mm.
MINI 51
Max 10W - GU10
100-240V - 50/60Hz
ON/OFF
Bulb not included
Matt White - ON/OFF
1A0660300.00.00
Matt Black - ON/OFF
1A0660400.00.00
