381
380
Omar Carraglia - Davide Groppi / 2015
DOT R
DOT R
Omar Carraglia - Davide Groppi / 2015
Compulsory accessories / Accessori obbligatori
Drivers / Alimentatori
Driver / Alimentatore
Not included
220-240V(100-127V)
350mA/17W(15W)/IP20/DALI
DOT R
1Z0241180.350
Driver / Alimentatore
Not included
220-240V(100-127V)
350mA/18W(15W)/IP20/PUSH - 1-10V
DOT R
1Z0240870.350
Driver / Alimentatore
Not included
220-240V
350mA/17W/IP20/TRIAC/IGBT
DOT R
1Z0240850.350
Other accessories / Altri accessori
Lens / Lente
Not included
Beam - 14°
2700K - CRI >97 - 983lm
DOT R
1A3090000.00.00
3000K - CRI >97 - 1038lm
Beam - 24°
2700K - CRI >97 - 943lm
DOT R
1A3100000.00.00
3000K - CRI >97 - 996lm
Beam - 36°
2700K - CRI >97 - 955lm
DOT R
1A3110000.00.00
3000K - CRI >97 - 1005lm
Beam - 50°
2700K - CRI >97 - 965lm
DOT R
1A3120000.00.00
3000K - CRI >97 - 1016lm
Recessed / Direct / Indoor
Material
Metal
Finish
.03 Matt White
.04 Matt Black
.49 Matt Black/Polished Gold
Note
Recessed luminaire. Adjustable in all directions. Plasterboard hole:
40x40 mm. Minimum space for recessed installation: 40 mm.
Apparecchio illuminante da incasso. Orientabile in tutte le direzioni.
Foro del cartongesso: 40x40 mm. Spazio minimo per incasso: 40 mm.
DOT R
13W
Max 350mA DC
2700K / 3000K
CRI >97
Driver not included
Matt White - 2700K
1A4770300.27.20
Matt White - 3000K
1A4770300.30.20
Matt Black - 2700K
1A4770400.27.20
Matt Black - 3000K
1A4770400.30.20
Matt Black/Polished Gold - 2700K
1A4774900.27.20
Matt Black/Polished Gold - 3000K
1A4774900.30.20
DOT R 51
Max 10W - GU10
100-240V - 50/60Hz
ON/OFF
Bulb not included
Matt White - ON/OFF
1A3700300.00.00
Matt Black - ON/OFF
1A3700400.00.00
Matt Black/Polished Gold - ON/OFF
1A3704900.00.00
