312
311
/ 2001
SPOT
SPOT
/ 2001
Optional accessories / Accessori opzionali
Other accessories / Altri accessori
Accessory holder + Soft filter + Honeycomb louvre / Porta accessori + Filtro soft + Frangiluce nido d'ape
Not included
Matt Black
1X0070400.04.00
Accessory holder + Elliptical filter / Porta accessori + Filtro ellittico
Not included
Matt Black
1X0070400.05.00
Blue filter / Filtro blu
Not included
Standard
Compulsory with
1X0070400.04.00 / 1X0070400.05.00
1X0070000.06.00
Red filter / Filtro rosso
Not included
Standard
Compulsory with
1X0070400.04.00 / 1X0070400.05.00
1X0070000.07.00
Yellow filter / Filtro giallo
Not included
Standard
Compulsory with
1X0070400.04.00 / 1X0070400.05.00
1X0070000.08.00
35
120
Horizontal directional fins / Alette direzionali
Not included
Matt Black
1X0070400.01.00
Cylindrical screen / Schermo cilindrico
Not included
Matt Black
1X0070400.02.00
Cone 45° / Cono 45°
Not included
Matt Black
1X0070400.03.00
Compulsory accessories / Accessori obbligatori
LED modules / Moduli LED
DG111 LED module / Modulo LED DG111
Not included
16,7W - 15° - 500mA DC
2700K - 1648lm - CRI >90
Energy Efficiency F - Dimmable
SPOT
1A4700000.27.20
16,7W - 15° - 500mA DC
3000K - 1682lm - CRI >90
Energy Efficiency F - Dimmable
1A4700000.30.20
DG111 LED module / Modulo LED DG111
Not included
16,7W - 22° - 500mA DC
2700K - 1859lm - CRI >90
Energy Efficiency F - Dimmable
SPOT
1A3890000.27.20
16,7W - 22° - 500mA DC
3000K - 1945lm - CRI >90
Energy Efficiency F - Dimmable
1A3890000.30.20
DG111 LED module / Modulo LED DG111
Not included
16,7W - 36° - 500mA DC
2700K - 1808lm - CRI >90
Energy Efficiency F - Dimmable
SPOT
1A3900000.27.20
16,7W - 36° - 500mA DC
3000K - 1890lm - CRI >90
Energy Efficiency F - Dimmable
1A3900000.30.20
DG111 LED module / Modulo LED DG111
Not included
11,7W - 15° - 350mA DC
2700K - 1336lm - CRI >90
Energy Efficiency F - Dimmable
SPOT ENDLESS /
SPOT ENDLESS CASAMBI
1A4700000.27.20
11,7W - 15° - 350mA DC
3000K - 1364lm - CRI >90
Energy Efficiency F - Dimmable
1A4700000.30.20
DG111 LED module / Modulo LED DG111
Not included
11,7W - 22° - 350mA DC
2700K - 1266lm - CRI >90
Energy Efficiency F - Dimmable
SPOT ENDLESS /
SPOT ENDLESS CASAMBI
1A3890000.27.20
11,7W - 22° - 350mA DC
3000K - 1323lm - CRI >90
Energy Efficiency F - Dimmable
1A3890000.30.20
DG111 LED module / Modulo LED DG111
Not included
11,7W - 36° - 350mA DC
2700K - 1508lm - CRI >90
Energy Efficiency F - Dimmable
SPOT ENDLESS /
SPOT ENDLESS CASAMBI
1A3900000.27.20
11,7W - 36° - 350mA DC
3000K - 1578lm - CRI >90
Energy Efficiency F - Dimmable
1A3900000.30.20
