225
224
Davide Groppi / 2023
SOTTILE
SOTTILE
Davide Groppi / 2023
5000
7
1400
50
SOTTILE 2
Remote driver version
19W
24V DC
2700K - 1692lm / 3000K - 1855lm
CRI >90
Driver not included
Brushed Bronze - 2700K
1A4232900.27.20
Brushed Bronze - 3000K
1A4232900.30.20
Brushed Black - 2700K
1A4233600.27.20
Brushed Black - 3000K
1A4233600.30.20
5000
7
1400
50
SOTTILE 2 DE
Remote driver version - Dual emission
2x19W
24V DC
2700K - Up 1692lm - Down 1692lm /
3000K - Up 1855lm - Down 1855lm
CRI >90
Driver not included
Brushed Bronze - 2700K
1A4642900.27.20
Brushed Bronze - 3000K
1A4642900.30.20
Brushed Black - 2700K
1A4643600.27.20
Brushed Black - 3000K
1A4643600.30.20
Compulsory accessories / Accessori obbligatori
Drivers / Alimentatori
Driver / Alimentatore
Not included
100-240V
24V/50W/IP20/ON/OFF
SOTTILE 2 / SOTTILE 2 DE
1Z1120490
Controller
Not included
DALI - PUSH - 0/1-10V - TRIAC - IP20
SOTTILE 2 / SOTTILE 2 DE
1Z2170010
Suspension / Direct / Indoor
Material
Metal
Finish
.29 Brushed Bronze
.36 Brushed Black
Note
Suspension luminaire. Matt white rose. AISI 304 stainless steel
suspension cable. Black cable. Luminaire designed to be powered by
our ENDLESS conductive tape and dedicated voltage/current (Max
48V DC - Max 150W - Max 4A). See page: ENDLESS. SOTTILE 1 DE and
SOTTILE 2 DE: mono on/off and dual emission version. SOTTILE 2 and
SOTTILE 2 DE: version with power cable only and without rose.
Apparecchio illuminante a sospensione. Rosone bianco opaco. Cavo di
sospensione in inox AISI 304. Cavo nero. Alimentabile anche con il tape
conduttivo ENDLESS e tensione/corrente dedicata (Max 48V DC - Max 150W
- Max 4A). Vedi pagina ENDLESS. SOTTILE 1 DE e SOTTILE 2 DE: versione
monoaccensione a doppia emissione. SOTTILE 2 e SOTTILE 2 DE: versione
con solo il cavo di alimentazione e senza rosone.
SOTTILE 1
Ceiling driver version
21W
220-240V - 50/60Hz
2700K - 1692lm / 3000K - 1855lm
CRI >90
Driver integrated
DALI - PUSH - 1-10V - TRIAC
Brushed Bronze - 2700K - DALI - PUSH - 1-10V - TRIAC
1A4232900.27.05
Brushed Bronze - 3000K - DALI - PUSH - 1-10V - TRIAC
1A4232900.30.05
Brushed Black - 2700K - DALI - PUSH - 1-10V - TRIAC
1A4233600.27.05
Brushed Black - 3000K - DALI - PUSH - 1-10V - TRIAC
1A4233600.30.05
SOTTILE 1 DE
Ceiling driver version - Dual emission
41W
110-240V - 50/60Hz
2700K - Up 1692lm - Down 1692lm /
3000K - Up 1855lm - Down 1855lm
CRI >90
Driver integrated
DALI - PUSH - 1-10V - TRIAC
Brushed Bronze - 2700K - DALI - PUSH - 1-10V - TRIAC
1A4642900.27.05
Brushed Bronze - 3000K - DALI - PUSH - 1-10V - TRIAC
1A4642900.30.05
Brushed Black - 2700K - DALI - PUSH - 1-10V - TRIAC
1A4643600.27.05
Brushed Black - 3000K - DALI - PUSH - 1-10V - TRIAC
1A4643600.30.05
