Sypha
(outdoor)
[ Finishes ] // Stems - the stems of the Sypha collection are made of brass (Syphaduepassi) or black coloured iron
(Syphasera and Syphasfera). / Untreated brass (an alloy of copper and zinc) is a very elegant finish, yellow-gold in
colour, with an excellent corrosion resistance. We use it untreated, therefore it may oxidise with time. Regular cleaning
helps preserving its original appearance and slow down the ageing process, which might be anyway accelerated by the
weather, frequent handling or conditions of high humidity.
[ Note ] // The lumen value refers to the rated lumen output of the light source; for the lamp’s output please refer to our bim files (see website). /
( * ) IP specifics: lamp holder IP65 (not protected against immersion); wires and connectors IP68; not resistant to salt fog.
p. 367
Syphasera / standing lamp / driver and accessories not incl. (see pages 118-123)
voltage
source
type
watt
lumen
K
CRI
en. class
driver/transformer
dimming
Ø 1,5x21 cm
65/80/110/140 cm
25 cm
SYS65 / H 65 cm / black stem / brass details / opaline glass / grey-transparent cable 255 cm
-
low voltage
LED 12Vdc
G4 bulb
(IP65 lampholder)*
1x0,8W
67
2700
80
F
not included
available on request
-
SYS80 / H 80 cm / black stem / brass details / opaline glass / grey-transparent cable 240 cm
SYS110 / H 110 cm / black stem / brass details / opaline glass / grey-transparent cable 210 cm
SYS140 / H 140 cm / black stem / brass details / opaline glass / grey-transparent cable 180 cm
p. 368
Syphasfera / standing lamp / driver and accessories not incl. (see pages 118-123)
voltage
source
type
watt
lumen
K
CRI
en. class
driver/transformer
dimming
25 cm
Ø 8 cm
60/75/105/135 cm
SYF60 / H 60 cm / black stem / brass details / transparent glass / grey-transparent cable 255 cm
-
low voltage
LED 12Vdc
G4 bulb
(IP65 lampholder)*
1x0,8W
69
2700
80
G
not included
available on request
-
SYF60I / H 60 cm / black stem / brass details / irreg. transp. glass / grey-transparent cable 255 cm
SYF75 / H 75 cm / black stem / brass details / transparent glass / grey-transparent cable 240 cm
SYF75I / H 75 cm / black stem / brass details / irreg. transp. glass / grey-transparent cable 240 cm
SYF105 / H 105 cm / black stem / brass details / transparent glass / grey-transparent cable 210 cm
SYF105I / H 105 cm / black stem / brass details / irreg. transp. glass / grey-transparent cable 210 cm
SYF135 / H 135 cm / black stem / brass details / transparent glass / grey-transparent cable 180 cm
SYF135I / H 135 cm / black stem / brass details / irreg. transp. glass / grey-transparent cable 180 cm
p. 371
Syphaduepassi / standing lamp / driver and accessories not incl. (see pages 118-123)
voltage
source
type
watt
lumen
K
CRI
en. class
driver/transformer
dimming
45/75 cm
25 cm
SYD45 / H 45 cm / brass stem and details / grey-transparent cable 225 cm
-
low voltage
LED 12Vdc
G4 bulb
(IP65 lampholder)*
1x0,8W
67
2700
80
F
not included
available on request
-
SYD75 / H 75 cm / brass stem and details / grey-transparent cable 195 cm
