p. 234
Stchu-Moon Chandelier / pendant lamp
voltage
source
type
watt
lumen
K
CRI
en. class
driver/transformer
dimming
Ø 7x6,5 cm
34 cm
Ø 19,5 cm
SM234LS / Ø 40 cm silver (exterior black) / steel spoons / black cables and structure
230V
(110V available 1…10V
or push dimm.)
constant voltage 24V
LED board
6x3,9W
23,4W
2520
2700
80
F
constant voltage driver
Triac***
SM234LG / Ø 40 cm gold (exterior black) / steel spoons / black cables and structure
SM234LC / Ø 40 cm copper (exterior black) / steel spoons / black cables and structure
SM236LS / Ø 60 cm silver (exterior black) / steel spoons / black cables and structure
SM236LG / Ø 60 cm gold (exterior black) / steel spoons / black cables and structure
SM236LC / Ø 60 cm copper (exterior black) / steel spoons / black cables and structure
3x Ø 40 cm
H max 190 cm / tot. Ø 105 cm / weight 13,5 cm
3x Ø 60 cm
H max 200 cm / tot. Ø 145 cm / weight 18,5 cm
p. 239
Stchu-Moon 05 / wall lamp
voltage
source
type
watt
lumen
K
CRI
en. class
driver/transformer
dimming
40 cm
20 cm
30 cm
6 cm
SM5LS / silver (exterior white) / steel spoon / white base
230V
(110V available 1…10V
or push dimm.)
constant voltage 24V
LED board
1x3,9W
420
2700
80
F
constant voltage driver
Triac***
SM5LG / gold (exterior white) / steel spoon / white base
SM5LC / copper (exterior white) / steel spoon / white base
p. 242
Stchu-Moon 01 / floor lamp
voltage
source
type
watt
lumen
K
CRI
en. class
driver/transformer
dimming
Ø 40 cm
Ø 60 cm
SM14LS / Ø 40 cm silver (ext. black) / steel spoon / metal braided cable / black dimmer/cable
110-240V
constant voltage 24V
LED board
1x3,9W
420
2700
80
F
constant voltage
plug driver**
push included
(memory last step)
SM14LG / Ø 40 cm gold (ext. black) / steel spoon / metal braided cable / black dimmer/cable
SM14LC / Ø 40 cm copper (ext. black) / steel spoon / metal braided cable / black dimmer/cable
SM16LS / Ø 60 cm silver (ext. black) / steel spoons / metal braided cable / black dimmer/cable
2x3,9W
7,8W
840
SM16LG / Ø 60 cm gold (ext. black) / steel spoons / metal braided cable / black dimmer/cable
SM16LC / Ø 60 cm copper (ext. black) / steel spoons / metal braided cable / black dimmer/cable
p. 243
Stchu-Moon 09 / standing lamp
voltage
source
type
watt
lumen
K
CRI
en. class
driver/transformer
dimming
Ø 33x200 cm
50x50 cm
SM9LS / silver (rough iron ext.) / steel spoons / metal braided cable / black dimmer/cable
110-240V
constant voltage 24V
(1x candle included)
LED board
2x3,9W
7,8W
840
2700
80
F
constant voltage
plug driver**
push included
(memory last step)
SM9LG / gold (rough iron ext.) / steel spoons / metal braided cable / black dimmer/cable
SM9LC / copper (rough iron ext.) / steel spoons / metal braided cable / black dimmer/cable
