Medousê
(outdoor)
[ Finishes ] // Untreated brass (an alloy of copper and zinc) is a very elegant finish, yellow-gold in colour, with an
excellent corrosion resistance. We use it untreated, therefore it may oxidise with time. Regular cleaning helps preserving
its original appearance and slow down the ageing process, which might be anyway accelerated by the weather, frequent
handling or conditions of high humidity.
[ Note ] // The lumen value refers to the rated lumen output of the light source; for the lamp’s output please refer to our bim files (see website). /
( * ) Mains voltage LED modules and COB LED are dimmable using IGBT (trailing edge) dimmers designed specifically for LED sources. Their dimming is
extremely delicate: incompatible dimmers may cause irreparable damage to the LED. Some dimmers on the market have a NO button (Normally Open) or
are specific connector socket-mounted or recessed. They are generally inserted into junction boxes; their limited thickness facilitates the installer’s task and
makes the dimmer fit for installation even in shallow boxes. Dimmers with an integrated radio dimmer for both manual (NO button) and wireless control are
also available. It is important to note that during adjustment the dimming appears less precise, with some flickering. Furthermore some types of dimmer,
even if they have been recommended by the manufacturers themselves, have visible flickering (almost essentially down to a minimum) depending on the
mains and on the type of interference present. The problem can be solved by increasing the minimum value setting of the potentiometer on the dimmer. /
( ** ) IP specifics: LED module IP64; IP average rate of the lamp 44. / ( *** ) The LED modules provided for Medousê F and W have a starting temperature of
2.700K, as indicated in the manufacturer's datasheets. For their outdoor use, a protective resin is applied, which increases the temperature by 500K (CCT -
correlated color temperature), reaching approximately 3.200K. Currently, it is not possible to provide a color temperature different from this.
p. 339
Medousê / wall lamp
voltage
source
type
watt
lumen
K
CRI
en. class
driver/transformer
dimming
Ø 30 cm
MD3P / green glass / brass rod
230V
(110V)
mains voltage LED**
(mains voltage LED**)
LED module IP64
(LED module IP64)
1x17W
(1x14W)
1650
(1540)
3200***
(3200***)
80
(80)
A+
(A+)
-
IGBT/Triac*
(IGBT/Triac*)
MD3PTR / transparent glass / brass rod
p. 340
Medousê / floor lamp
voltage
source
type
watt
lumen
K
CRI
en. class
driver/transformer
dimming
Ø 30/50 cm
MD3 / Ø 30 cm / green glass / aluminium details / plug cable not included
230V
(110V)
mains voltage LED**
(mains voltage LED**)
LED module IP64
(LED module IP64)
1x24W
(1x29W)
2880
(2900)
3200***
(3200***)
90
(80)
E
(E)
-
IGBT/Triac*
(IGBT/Triac*)
MD3TR / Ø 30 cm / transparent glass / aluminium details / plug cable not included
MD5 / Ø 50 cm / green glass / aluminium details / plug cable not included
MD5TR / Ø 50 cm / transparent glass / aluminium details / plug cable not included
weight: Ø 30 cm 15 kg / Ø 50 cm 31 kg
