Luci d’Oro
[ Finishes ] // Nickel coating (metal plating process) is chosen by the designer for its elegant and warm finish. To
prevent any natural oxidation process, it requires regular cleaning. In alternative to nickel coating, customized finishes
(i.e. chrome plating) can be provided upon request. / Untreated brass (an alloy of copper and zinc) is a very elegant
finish, yellow-gold in colour, with an excellent corrosion resistance. We use it untreated, therefore it may oxidise with
time. Regular cleaning helps preserving its original appearance and slow down the ageing process, which might be
anyway accelerated by the weather, frequent handling or conditions of high humidity. / Rough iron (untreated metal)
is chosen by the designer specifically because of its uniqueness and its natural ageing property. The appearance of
any uneven rust patches does not constitute a defect, since it is a typical sign of the ageing process, which might be
considerably accelerated in conditions of high humidity or direct exposure to outdoor weathering.
[ Note ] // The lumen value refers to the rated lumen output of the light source; for the lamp’s output please refer to our bim files (see website). / ( * ) LED bulbs
can be dimmed using compatible dimmers, which have been tested specifically for dimming very low loads. The manufacturers of LED bulbs are required to
draw up a list of suggested dimmers for the dimming of their products, with an indication of the maximum number of bulbs dimmable with the various types
of dimmer. / ( ** ) Our LEDs can be dimmed by using compatible dimmers tested specifically to dim very low loads. We suggest checking the minimum load
of the dimmer before installation.
p. 239
Malagola / mod. 27 / pendant lamp
voltage
source
type
watt
lumen
K
CRI
en. class
driver/transformer
dimming
11 cm
27x13 cm
Ø 9x3,5 cm
170 cm
to be cut to size
ML27LG / gold / black base and cable
110-240V
constant current
LED 210 mA
COB LED
1x2W
300
2700
>80
F
constant current driver
NO
ML27LS / silver / black base and cable
ML27LC / copper / black base and cable
weight 0,9 kg
p. 239
Malagola / mod. 55 / pendant lamp
voltage
source
type
watt
lumen
K
CRI
en. class
driver/transformer
dimming
170 cm
to be cut to size
55x30 cm
Ø 9x3,5 cm
25 cm
ML55LG / gold / black-cloth cable / black base
110V (bulb not
supplied)-230V
mains voltage LED
E27 bulb
silver crowned
1x7W
600
2700
>80
F
-
IGBT/Triac*
ML55LS / silver / black-cloth cable / black base
ML55LC / copper / black-cloth cable / black base
weight 1,7 kg
p. 239
Malagola / mod. 110 / pendant lamp
voltage
source
type
watt
lumen
K
CRI
en. class
driver/transformer
dimming
110x45 cm
Ø 9x5 cm
170 cm
to be cut to size
45 cm
ML110LG / gold / black-cloth cable / black base
110V (bulbs not
supplied)-230V
mains voltage LED
E27 bulb
silver crowned
3x7W
21W
1800
2700
>80
F
-
IGBT/Triac*
ML110LS / silver / black-cloth cable / black base
ML110LC / copper / black-cloth cable / black base
weight 4,5 kg
