Material / Features
Polypropylene
- Material: Polypropylene resin with glass fiber , UV stabilizer.
- Process: injection moulding.
- Shock resistant.
- Light weight.
- 100% recyclable.
Polyethylene
- Material: resin. Linear low-density polethylene. Ul94 hb.
- Process: rotational moulding.
- Resistant to UVI. fattore UV8, equivalent to 8.000 hours of Florida sunlight.
- Resistant to extreme temperatures (-60ºC to + 80ºC) / ( -76ºF to 176ºF)
- Shock resistant.
- Light weight
- The planters are easily drilled to make draining holes.
- Recyclable 100%.
Polycarbonate
- Material: polycarbonate resin. Low viscosity, high strength.
- Process: injection moulding.
- Shock resistant.
- Light weight
- Recyclable 100%.
Aluminium (table base)
- Material: AISI12 (EN AC-44100).
- Process: cast aluminum.
- Shock resistant.
- Recyclable 100%.
- Powder coated cast aluminum.
Aluminum (profile)
- Material: 6060 (AlMgSi,3.3206,A96060).
- Process: aluminum extrusion.
- Shock resistant.
- Recyclable 100%.
- Lacquered.
Iroko Wood
- Hard and very resistant wood.
- Process: Machining.
- Shock and outdoor resistant.
- Recyclable 100%.
- Varnished to avoid rain stains.
Teak Wood
- Premium Indonesian teak is durable and exceptionally resistant to the elements
- Natural Teak weathers to a soft, silver-grey patina over time due to the effects of sun and
moisture
- Please check the web for maintenance and care of teak
Weathered Teak Wood
- Premium Indonesian teak is durable and exceptionally resistant to the elements
- Weathered Teak’s hand-applied, wire-brush finish offers an already Weathered look
- Please check the web for maintenance and care of teak
Polyurethane Foam (Upholstered Furniture)
Furniture made produced with Polyurethane foam injected. The foam has high resilience and du-
rability. The flexible Polyurethane foam is covered with a elastic cellular net that keeps the original
poduct’s shape after its use. Prevents fungal and bacterial growth.
Mechanical properties.
- Tensile strength resistance: between 3 & 10 (Kp./cm2)
- Compression resistance: between 1,5 & 9 (Kp./cm2)
- Shear strength resistance: between 1 & 5 (Kp./cm2)
- Modulus of elasticity: between 40 & 200 (Kp./cm2)
Table Tops / Features
HPL / Solid Core
HPL Tabletops for Mari-sol, Faz and Delta table bases thickness is 10mm ± 0,55.
Thickness
ISO 4586 ½
mm
13 ± 0,55
Density
ISO 1183
Kg/m3
1400 - 1500
Water absorption
ISO 4586 ½
%
Weight
2,0 max.
Thickness
2,0 max.
Dimensional stability at
high temperatures
ISO 4586 ½
%
Long.
0,25 max.
Trans.
0,55 max.
Hardness
ASTM D 785
HR E
97 ca
Bending strength
ISO 178
MPa
MPa
Long.
145 min
Trans
135 min
Glass
Security tempered glass. Thickness: 10 mm.
Technical Features
Units
Value
Resistant to soft body impact
2(B)2
Resistance against suddne temperature changes
K
40
Resistant to wind, snow and large weight
mm
10
Sound insulation
dB
34 (-1,-3)
Thermal Transmittance (value U)
W/(m2,K)
5.6
Light Transmission tV
0.53
Light Refletion pV
0.06/0.06
Solar Transmission tE
0.52
Solar Reflection pE
0.06/0.06
Concrete
Furniture elements manufactured in high-strength fibrated mortar, by casting and vibrating in
elastomer moulds and rigid fiberglass shell.
- 2.4 g/cm3 density
- Water-repellent protection
- Oil repellent protection
- Diamond abrasive roughening
Technical Information
Fabrics / Features
Padded Foam
Polyurethane foam is suitable for outdoor use and in areas with high humidity. Perfectly water-
proof, high drying capacity, comfortable and easily cleaned.
Properties
Unit
Value
Specifications
Composition
-
100% Polyester
-
Maximum temperature
ºC
110.0
±1.0
Manufacturing process
Dry carded and termal drying
Recyclability
100%, without additives or binding agents
Other caractherics:
- It does not absorb or retain moisture.
- It is not affected by mould, insects or rodents.
- It does not cause irritation to the skin or the mucous membranes.
Fabric
Weight
Flame Resistance
Resistance
Color Fastness
Composition
Maintenance
Symbols
Altea.
Soft acrylic outdoor fabric
with leather-like texture.
657 gr/m2
EN 1021 1-2
DIN 4102 B2
BS 5852
DIN 53438/T2
CAL TB 117
>100.000
cycles
XENOTEST DIN 54004/
NTC 1479
ASTM D-4329/ CFFA-2
c2
Vinyl Coating,
100% Polyester
Backing
Clean using a cotton cloth with
neutral soap 1/9 water solution.
Rub dry with a clean cloth and
let it dry.
Arousa.
Soft-shiny acrylic outdoor
fabric.
685 gr/m2
EN 1021 1-2
DIN 4102 B2
NF P 92-503 / M2
UNE 23.727-90 IR/ M2
IMO MSC.307
CAL TB 117
>300.000
cycles
>7 - DIN 54004
NTC 1479
(UV outdoor)
4 - ISO 105B04
Vinyl Coating,
100% Polyester
Backing
Clean using a cotton cloth with
neutral soap 1/9 water solution.
Rub dry with a clean cloth and
let it dry.
