10
11
Butterfly nut
10
10
Showcase & Display
www.formalighting.com
IP20
360O
90O
Bonsai — EL = Eliptical Beam (29° x 44°).
Bonsai Alto — EL = Eliptical Beam (22° x 32°).
For the most updated product information, please go to our website.
1 For complete code ordering information, please see pages 19.
2 Other CCT options available on request.
Bonsai
Bonsai Alto
Product
Code 1
Height
Code
LED
Power
Nominal
Lumen
Beam Angle
(BAº)
Min.
Max.
CRI>97
3000K
High
Rendering
Bonsai
G160
H060
H500
0.6W
71 lm
25º / EL
Bonsai x 2
G167
H110
0.6W x 2
71 lm x 2
Bonsai x 3
G157
H160
0.6W x 3
71 lm x 3
Bonsai Alto
G161
H060
H500
1W
132 lm
21º / 25º / EL
Bonsai Alto x 2
G162
H110
1W x 2
132 lm x 2
Bonsai Alto x 3
G163
H160
1W x 3
132 lm x 3
Ø 8 mm
[Ø 0.31”]
Ø 12 mm
[Ø 0.47”]
Middle spot
Bonsai
Bonsai Alto
Top spot
G157
G167
G160
360°
90°
G161
G162
G163
Max. total length:
500 mm [19.69”]
Min. total length:
160 mm [6.30”]
Min. total length:
110 mm [4.33”]
Min. total length:
60 mm [2.36”]
Diameter of pole:
Ø 5 mm [Ø 0.20”]
50 mm
[1.97”]
50 mm
[1.97”]
Max. total length:
500 mm [19.69”]
Dimming
Options
00
No Driver
CCT
Options 2
27
2700K
30
3000K
35
3500K
40
4000K
50 mm
[1.97”]
50 mm
[1.97”]
50 mm
[1.97”]
50 mm
[1.97”]
30 mm
[1.18”]
Diameter of pole:
Ø 5 mm [Ø 0.20”]
Ø 8 mm
[Ø 0.31”]
Ø 12 mm
[Ø 0.47”]
50 mm
[1.97”]
50 mm
[1.97”]
30 mm
[1.18”]
13.9 mm
[0.55”]
22 mm
[0.87”]
360°
