63
62
MISS
Omar Carraglia / 2006
Omar Carraglia / 2006
MISS
MISS
4W
Max 350mA DC
2700K - 290lm / 3000K - 310lm
CRI >90
Driver not included
Matt White - 2700K
1A2960300.27.20
Matt White - 3000K
1A2960300.30.20
Matt Black - 2700K
1A2960400.27.20
Matt Black - 3000K
1A2960400.30.20
Brushed Brass - 2700K
1A2960800.27.20
Brushed Brass - 3000K
1A2960800.30.20
Total Black - 2700K
1A2962600.27.20
Total Black - 3000K
1A2962600.30.20
Polished Black Chrome - 2700K
1A2962800.27.20
Polished Black Chrome - 3000K
1A2962800.30.20
MISS ENDLESS
Endless version only
6,3W - 0,16A
48V DC
2700K - 290lm / 3000K - 310lm
CRI >90
Driver not included
See page ENDLESS
Matt White - 2700K
1A2960300.27.40
Matt White - 3000K
1A2960300.30.40
Matt Black - 2700K
1A2960400.27.40
Matt Black - 3000K
1A2960400.30.40
Brushed Brass - 2700K
1A2960800.27.40
Brushed Brass - 3000K
1A2960800.30.40
Total Black - 2700K
1A2962600.27.40
Total Black - 3000K
1A2962600.30.40
Polished Black Chrome - 2700K
1A2962800.27.40
Polished Black Chrome - 3000K
1A2962800.30.40
Compulsory accessories / Accessori obbligatori
Suspension kits / Kit di sospensione
Ceiling rose with driver / Rosone con alimentatore
Not included
Matt White
Input 220-240V - 50/60Hz
Output 350mA DC - Max 4W
IP20 - ON/OFF
MISS
1X0230300.01.00
Matt Black
Input 220-240V - 50/60Hz
Output 350mA DC - Max 4W
IP20 - ON/OFF
MISS
1X0230400.01.00
Ceiling rose with driver / Rosone con alimentatore
Not included
Matt White
Input 110-240V - 50/60Hz
Output 350mA DC - Max 4W
IP20 - DALI - PUSH - 1-10V
MISS
1X0230300.02.07
Matt Black
Input 110-240V - 50/60Hz
Output 350mA DC - Max 4W
IP20 - DALI - PUSH - 1-10V
MISS
1X0230400.02.07
Matt White
Input 220-240V - 50/60Hz
Output 350mA DC - Max 4W
IP20 - TRIAC/IGBT
MISS
1X0230300.03.02
Matt Black
Input 220-240V - 50/60Hz
Output 350mA DC - Max 4W
IP20 - TRIAC/IGBT
MISS
1X0230400.03.02
Compulsory accessories / Accessori obbligatori
Suspension kits / Kit di sospensione
Ceiling rose without driver / Rosone senza alimentatore
Not included
Matt White
For electrical cables - 1 Piece
MISS
1X0010300.06.00
Matt Black
For electrical cables - 1 Piece
MISS
1X0010400.06.00
Recessed rose without driver / Rosone da incasso senza alimentatore
Not included
Matt White
For electrical cables - 1 Piece
Plasterboard cut-out Ø 44 mm
Minimum space for mounting 70 mm
For 12,5 mm plasterboard
MISS
1X0000300.06.00
Matt Black
For electrical cables - 1 Piece
Plasterboard cut-out Ø 44 mm
Minimum space for mounting 70 mm
For 12,5 mm plasterboard
MISS
1X0000400.06.00
Recessed rose without driver / Rosone da incasso senza alimentatore
Not included
Matt White
Plasterboard cut-out 85x97 mm
Minimum space for mounting 120 mm
For 12,5 mm plasterboard
MISS
1X0230300.04.00
Matt Black
Plasterboard cut-out 85x97 mm
Minimum space for mounting 120 mm
For 12,5 mm plasterboard
MISS
1X0230400.04.00
BINARIO TRIFASE adapter / Adattatore per BINARIO TRIFASE
Not included
Matt White
Input 220-240V - 50/60Hz
Output 350mA DC - Max 14,7W
IP20 - DALI
MISS
1X0230300.05.01
Matt Black
Input 220-240V - 50/60Hz
Output 350mA DC - Max 14,7W
IP20 - DALI
MISS
1X0230400.05.01
Drivers / Alimentatori
Driver / Alimentatore
Not included
220-240V
350mA/17W/IP20/TRIAC/IGBT
MISS
1Z0240850.350
Driver / Alimentatore
Not included
220-240V(110-127V)
350mA/18,9W(13,5W)/IP20/DALI - PUSH
- 1-10V
MISS
1Z0241270.350
