387
386
D7
/ 2025
/ 2025
D7
D7 - 24°
12W
Max 350mA DC
2700K - 1184lm / 3000K - 1406lm
CRI >90
Beam 24°
Driver not included
Matt Black - 2700K
1A6220400.27.20
Matt Black - 3000K
1A6220400.30.20
D7 - 38°
12W
Max 350mA DC
2700K - 1157lm / 3000K - 1374lm
CRI >90
Beam 38°
Driver not included
Matt Black - 2700K
1A6230400.27.20
Matt Black - 3000K
1A6230400.30.20
D7 - 50°
12W
Max 350mA DC
2700K - 1110lm / 3000K - 1319lm
CRI >90
Beam 50°
Driver not included
Matt Black - 2700K
1A6240400.27.20
Matt Black - 3000K
1A6240400.30.20
Compulsory accessories / Accessori obbligatori
Installation kits / Kit d'installazione
Plasterboard frame 12,5 mm / Cornice per cartongesso 12,5 mm
Not included
Matt White
Cut-out 104x104 mm
Minimum space for mounting 130 mm
1A3500300.00.00
Matt Black
Cut-out 104x104 mm
Minimum space for mounting 130 mm
1A3500400.00.00
Drivers / Alimentatori
Driver / Alimentatore
Not included
220-240V(110-127V)
350mA/18,9W(13,5W)/IP20/DALI - PUSH
- 1-10V
1Z0241270.350
Driver / Alimentatore
Not included
220-240V
350mA/14W/IP20/TRIAC/IGBT
1Z2270060.350
Optional accessories / Accessori opzionali
Other accessories / Altri accessori
Honeycomb louvre / Frangiluce nido d'ape
Not included
Standard
1X0130000.01.00
