Davide Groppi / 2023
SOTTOSOPRA
SOTTOSOPRA
Davide Groppi / 2023
Compulsory accessories
Suspension kits
Ceiling rose without driver
Not included
Matt White
For electrical cables - 1 Piece
SOTTOSOPRA 2
1X0010300.05.00
Matt Black
For electrical cables - 1 Piece
SOTTOSOPRA 2
1X0010400.05.00
Recessed rose without driver
Not included
Matt White
For electrical cables - 1 Piece
Plasterboard cut-out Ø 1.73"
Minimum space for mounting 2.76"
For 0.49" plasterboard
SOTTOSOPRA 2
1X0000300.05.00
Matt Black
For electrical cables - 1 Piece
Plasterboard cut-out Ø 1.73"
Minimum space for mounting 2.76"
For 0.49" plasterboard
SOTTOSOPRA 2
1X0000400.05.00
Wall adapter plate
Not included
Matt White
SOTTOSOPRA 2
1X0050300.01.00
Drivers
Driver for uplight emission
Not included
120-277V
350mA/30W/IP20/1-10V - TRIAC
SOTTOSOPRA 2
1Z2020050.350
Driver for downlight emission
Not included
110-240V
500mA/10W/IP20/1-10V - TRIAC
SOTTOSOPRA 2
1Z2340010.500
Driver for uplight emission
Not included
220-240V(110-127V)
350mA/18,9W(13,5W)/IP20/DALI - PUSH
- 1-10V
SOTTOSOPRA 2
1Z0241270.350
Driver for downlight emission
Not included
220-240V(110-127V)
500mA/25W(13,5W)/IP20/DALI - PUSH
- 1-10V
SOTTOSOPRA 2
1Z0241270.500
SOTTOSOPRA 1
Ceiling driver version
22W
120V - 60Hz
2700K - Up 210lm - Down 366lm /
3000K - Up 263lm - Down 366lm
CRI >90
UGR <19
Driver integrated
TRIAC/IGBT
Matt White - 2700K - TRIAC/IGBT
1A4540303.27.02
Matt White - 3000K - TRIAC/IGBT
1A4540303.30.02
SOTTOSOPRA 1
Ceiling driver version
22W
120V - 60Hz
2700K - Up 210lm - Down 366lm /
3000K - Up 263lm - Down 366lm
CRI >90
UGR <19
Driver integrated
DALI - PUSH - 1-10V
Matt White - 2700K - DALI - PUSH - 1-10V
1A4540303.27.07
Matt White - 3000K - DALI - PUSH - 1-10V
1A4540303.30.07
SOTTOSOPRA 2
Remote driver version
19W
Up Max 350mA DC - Down Max 500mA DC
2700K - Up 210lm - Down 366lm /
3000K - Up 263lm - Down 366lm
CRI >90
UGR <19
Driver not included
2 Drivers required
Matt White - 2700K
1A4540303.27.20
Matt White - 3000K
1A4540303.30.20
+
+
