TECHNICAL INFORMATION
COMPONENTS
CABLE CONCENTRATOR
CONNECTION BOX
FOR
MODEL
REFERENCE
Ø102
40
.25
.35
CB10
Ø150
26
.45
.65
CB02
47
Ø310
.95
.125
CB05
CENTRAL ROD SUSPENSION
CONNECTION BOX
DIMENSIONS
REFERENCE
+
Ø102
40
600 mm
SC20.60
800 mm
SC20.80
1000 mm
SC20.100
TILT SUSPENSION ROD
CONNECTION BOX
DIMENSIONS
REFERENCE
+
+
Ø102
40
800 mm
SC20.80
1000 mm
SC20.100
CABLE CONCENTRATOR KIT
CONNECTION BOX
FOR
MODEL
REFERENCE
Ø85
+
CB10
.25
.35
SC21
Ø125
+
CB02
.45
.65
SC22
Ø215
+
CB05
.95
.125
SC23
SUSPENSION KIT 5m
5m
SC05.SA
SUSPENSION KIT 7m
7m
SC07.SA
SUSPENSION KIT 10m
10m
SC10.SA
FINISH
B · Black
W · White
S · Special color
ONLY FOR SIZES
350 · 450
PENDANT
TILT ACCESSORY
ON DEMAND OPTIONS
Special
finishes
Number
switches
Surface/Wall sfc.
up light
Emergency
lighting
Motion
detection
Wireless
control options
POWER STANDARD
FINISH
B · Black
W · White
S · Special color
DIMM OPTIONS
O · On-Off
D · Dali
P · Push
Up light
Down light
Ø250
Ø350
Ø450
24 V
10 W
681 - 713 - 765 lm
13 W
908 - 950 - 1020 lm
18 W
1287 - 1346 - 1445 lm
250 mA
12 W
1385 - 1400 - 1425 lm
19 W
2350 - 2392 - 2697 lm
38 W
4700 - 4784 - 5394 lm
Opal
2700 K
106EB
112
106EC
112
106ED
112
3000 K
106EB
113
106EC
113
106ED
113
4000 K
106EB
115
106EC
115
106ED
115
Microprismatic
2700 K
106EB
122
106EC
122
106ED
122
3000 K
106EB
123
106EC
123
106ED
123
4000 K
106EB
125
106EC
125
106ED
125
Ø650
Ø950
Ø1250
24 V
25 W
1816 - 1900 - 2040 lm
37 W
2724 - 2850 - 3060 lm
48 W
3556 - 3721 - 3995 lm
250 mA
87 W
10572 - 10704 - 12484 lm
177 W
21598 - 21976 - 25816 lm
350 W
36308 - 36848 - 43124 lm
Opal
2700 K
106EF
112
106EI
112
106EK
112
3000 K
106EF
113
106EI
113
106EK
113
4000 K
106EF
115
106EI
115
106EK
115
Microprismatic
2700 K
106EF
122
106EI
122
106EK
122
3000 K
106EF
123
106EI
123
106EK
123
4000 K
106EF
125
106EI
125
106EK
125
Opal
Microprismatic
INSTALLATION
1 · Pendant
2 · Pendant up light
3 · Surface
7 · Wall Surface
9 · Trackline
The data shown corresponds to raw values.
Luminaire .95 and .125 require 3 rod suspensions.
