INSTALLATION
FLORIDA SQ
5. WALL SURFACE
D
E
E
40
50
114
F
C
D
2. SURFACE
G
C
40
50
114
D
D
E
F
E
1. PENDANT - PENDANT UP LIGHT
C
40
50
114
D
E
F
E
A
B
D
4. TRIMLESS
D
G
G
E
C
40
50
114
D
F
E
150mm
IP20
IP43
DIMENSION
366 x 366
353 x 353
466 x 466
453 x 453
666 x 666
653 x 653
966 x 966
953 x 953
1266 x 1266
1253 x 1253
3. RECESSED WITH FRAME
G
D
E
G
C
8
50
114
D
F
E
214mm
IP20
IP43
DIMENSION
350 x 350
360 x 360
450 x 450
460 x 460
650 x 650
660 x 660
950 x 950
960 x 960
1250 x 1250
1260 x1260
Cut hole
Minimum height of the false ceiling
Luminaire not suitable to be covered
with thermal insulating material
WIDTH × LENGTH mm.
350 x 350 · 450 x 450 · 650 x 650
950 x 950 · 1250 x 1250
HEIGHT mm.
114
A - 4× aircraft cable (3 m)
B - Power cable
C - LED module
D - Diffuser
E - Aluminium profile
F - Aluminium cover
G - Mounting kit
H - Included connection box
