ALBERTA FAMILY
ALBERTA SOFT OUTSIDE
73
72
TECHNICAL INFORMATION
COMPONENTS
CABLE CONCENTRATOR
CONNECTION BOX
FOR
MODEL
REFERENCE
Ø102
40
.35
CB10
Ø150
26
.45
.65
CB02
47
Ø310
.95
.125
.150
CB05
CABLE CONCENTRATOR KIT
CONNECTION BOX
FOR
MODEL
REFERENCE
Ø85
+
CB10
.35
SC21
Ø125
+
CB02
.45
.65
SC22
Ø215
+
CB05
.95
.125
.150
SC23
SUSPENSION KIT 5m
5m
SC05.SA
SUSPENSION KIT 7m
7m
SC07.SA
SUSPENSION KIT 10m
10m
SC10.SA
PENDANT
FINISH
B · Black
W · White
S · Special color
ON DEMAND OPTIONS
Special
finishes
Number
switches
Tunable
white
RGB
Emergency
lighting
Motion
detection
Wireless
control options
Surface/Wall sfc.
up light
POWER HIGH
Int. Ø886 - Ext. Ø950
Int. Ø1186 - Ext. Ø1250
700 mA
86 W
6711 - 7248 - 7957 lm
113 W
8830 - 9537 - 10470 lm
Silicone
2700 K
143EI
112
143EK
112
3000 K
143EI
113
143EK
113
4000 K
143EI
115
143EK
115
Silicone
INSTALLATION
1 · Pendant
3 · Surface
7 · Wall Surface
FINISH
B · Black
W · White
S · Special color
DIMM OPTIONS
O · On-Off
D · Dali
P · Push
V · 1.10v
Outside light
The data shown corresponds to raw values.
