ESPIGA FAMILY
ESPIGA FAMILY
515
514
ESPIGA SOFT
LUMINAIRE INCLUDES
Recessed with frame mounting kit
Cut hole
Minimum height of the false ceiling
Luminaire not suitable to be covered
with thermal insulating material
.01
.02
.03
CEILING THICKNESS
13 mm
CEILING THICKNESS
10-20 mm
CEILING THICKNESS
10-20 mm
TRIMLESS
90
295 x 295
Ø85
290
65
290
TRIMLESS
90
335 x 335
Ø158
295
95
290
TRIMLESS
90
650 x 650
Ø395
645
277
645
ESPIGA SOFT
POWER GU5.3
.01
Max. 8 W LED
-
660EB6W400X
.01
Max. 8 W LED
.GU
660EB6W500X
POWER GU10
Down light
POWER STANDARD
POWER HIGH
.01
.02
.03
-
250 mA 8 W
1358 - 1380 - 1445 lm
500 mA 16 W
2720 - 2767 - 2888 lm
500 mA 11 W
1636 - 1938 - 2086 lm
Opal
2700 K
660EB6W112
660EE6W112
660EH6W112
3000 K
660EB6W113
660EE6W113
660EH6W113
4000 K
660EB6W115
660EE6W115
660EH6W115
.01
.03
-
350 mA 12 W
1784 - 1820 - 1866 lm
500 mA 22 W
3272 - 3876 - 4172 lm
Opal
2700 K
660EB6W312
660EH6W312
3000 K
660EB6W313
660EH6W313
4000 K
660EB6W315
660EH6W315
Opal
DIMM OPTIONS
O · On-Off
D · Dali
P · Push
V · 1.10v
The data shown corresponds to raw values.
