ZENIT FAMILY
ZENIT FAMILY
497
496
ZENIT SIDEREA ASYMETRIC
.01
.02
.03
Detalle de corte
LUMINAIRE INCLUDES
Recessed with frame mounting kit
CEILING THICKNESS
7-22 mm
CEILING THICKNESS
10-20 mm
CEILING THICKNESS
10-20 mm
TRIMLESS
120
Ø155
40
Ø150
TRIMLESS
120
205 x 205
200
200
70
TRIMLESS
185 430 x 305
425
300
145
Cut hole
Minimum height of the false ceiling
Luminaire not suitable to be covered
with thermal insulating material
40º
60º
45º
32º
45º
ZENIT SIDEREA ASYMETRIC
POWER STANDARD
.01
.02
.03
250 mA 8 W
1358 - 1380 - 1445 lm
250 mA 8 W
1358 - 1380 - 1445 lm
500 mA 18 W
1355 - 1538 - 1722 lm
40º
2700 K
650EB6W152
650EE6W152
650EH6W152
3000 K
650EB6W153
650EE6W153
650EH6W153
4000 K
650EB6W155
650EE6W155
650EH6W155
60º
2700 K
650EB6W172
650EE6W172
650EH6W172
3000 K
650EB6W173
650EE6W173
650EH6W173
4000 K
650EB6W175
650EE6W175
650EH6W175
POWER GU5.3
.01
.02
.03
Max. 8 W LED
Max. 8 W LED
Max. 20 W LED
-
650EB6W400X
650EE6W400X
650EH6W400X
POWER GU10
.01
.02
.03
Max. 8 W LED
Max. 8 W LED
Max. 20 W LED
.GU
650EB6W500X
650EE6W500X
650EH6W500X
POWER GU8.5
.03
Max. 20 W LED
.CD
650EH6W600X
Down light
DIMM OPTIONS
O · On-Off
D · Dali
P · Push
V · 1.10v
The data shown corresponds to raw values.
