33
BEAMS
Narrow
Wide
Very narrow
Very wide
Medium
IP20 | IK00
Insultaion class III
CRI>90
3W - 40W
195 - 3800lm
2700K - 3000K - 4000K
TECHNICAL SPECS
PRODUCT CODES
Family
Size
Class + Voltage
CRI° + K
Beam
Finish
D92/C = Eidos pendant
ceiling
35 = Ø35
45 = Ø45
55 = Ø55
65 = Ø65
75 = Ø75
85 = Ø85
3L = class III
low power
3H = class III
high power
(Remote driver
not included**)
927 = CRI>90
2700K
930 = CRI>90
3000K
940 = CRI>90
4000K
SN = super narrow
NB = narrow
MB = medium
WB = wide
VW = very wide
LW = embossed white
RAL 9010
LB = embossed black
RAL 9005
D92/C
35
3L
SN
927
LW
-
-
** Driver on-off or DALI is mandatory and to be ordered separately.
Driver phase-cut on request.
Check our website for drivers codes depending on product code.
