15
PRODUCT CODES
Family
Size
Class + Voltage
CRI° + K
Beam
Finish
D87 = Axel IP65
55 = cut-out Ø55
75 = cut-out Ø75
95 = cut-out Ø95
3 = class III
(Remote driver
not included*)
927 = CRI>90 - 2700K
930 = CRI>90 - 3000K
940 = CRI>90 - 4000K
NB = narrow
MB = medium
WB = wide
LW = embossed white
RAL 9010
LB = embossed black
RAL 9005
D87
55
3
927
NB
LW
/
-
-
BEAMS
Medium
Narrow
Wide
IP65 | IK02
Insulation class III
CRI>90
9W - 25W
720 - 2125lm
2700K - 3000K - 4000K
TECHNICAL SPECS
* Driver on-off or DALI is mandatory and to be ordered separately.
Driver phase-cut on request.
Check our website for drivers codes depending on product code.
