ULTERIORI COMPOSIZIONI A RICHIESTA (VEDI DA PAGINA 300 A PAGINA 309)
ADDITIONAL COMPOSITIONS ON DEMAND (SEE PAGES 300 TO 309)
Weitere Compositionen auf Anfrage (Seiten 300 bis 309)
MARK
©
Disegno depositato e registrato dall’EUIPO
COLORI, MATERIALI, FINITURE / CMF
COLORI VETRO DISPONIBILI / AVAILABLE GLASS COLOURS
01 - Trasparente
Transparent
SW - Bianco satinato
Satin white
03 - Rosa sfumato
Pink Nuanced
05 - Ambra
sfumato
Amber nuanced
06- Verde sfumato
Green nuanced
07 - Azzurro
sfumato
Sky-blue nuanced
08 - Fumè sfumato
Fume nuanced
16 - Tabacco
sfumato
Tobacco nuanced
17 - Rubino
sfumato
Ruby nuanced
FINITURA STRUTTURA/ CORPO METALLICO A VISTA DISPONIBILE / AVAILABLE METALLIC FINISHES FOR METAL-BODY-STRUCTURE
Cromo
Chrome
Cromo spazzolato
Brushed chrome
Oro satinato
Satin gold
(on request)
Nichel nero satinato
Satin black nickel
(on request)
Nero opaco
Matt black
Bianco opaco
Matt white
CARATTERISTICHE TECNICHE / TECHNICAL FEATURES
MATERIALI: VETRO BOROSILICATO E ALLUMINIO / MATERIALS: BOROSILICATE GLASS AND ALUMINIUM
COMPATIBILE CON CASAMBI / COMPATIBLE WITH CASAMBI
DIMMERABILE A TAGLIO DI FASE / TRIAC DIMMABLE
LED (COB) E DRIVER INCLUSI / LED (COB) AND DRIVER INCLUDED
SCHEDA LED SOSTITUIBILE DA PROFESSIONISTA / LED BOARD REPLACEABLE BY PROFESSIONAL
I LUMEN INDICATI CORRISPONDONO ALL’INTENSITÀ LUMINOSA ALL’ORIGINE DELLA SCHEDA LED / LUMEN INDICATED CORRESPONDS TO THE LUMINOUS
INTENSITY AT THE ORIGIN OF THE LED BOARD
DURATA DEL LED 50.000 ORE / LED LIFESPAN 50.000 HOURS
CAVO ELETTRICO COASSIALE A BASSA TENSIONE TRASPARENTE O NERO / COAXIAL LOW VOLTAGE ELECTRIC CABLE IN TRANSPARENT OR BLACK
SORGENTE LUMINOSA / LIGHTING SOURCE:
LED DISPONIBILE PER LAMPADA DA TAVOLO E SOSPENSIONI (1643, 1653, 1663) / LEDS AVAILABLE FOR TABLE LAMP AND HANGING LAMP (1643, 1653, 1663)
• LED 1x 6W - 11,2V-12,8V - 500mA - CRI Typ 95 - 866 Lm - 144 Lm/W - 180° - 3 Step MacAdam - 2700K or 3000K
LED DISPONIBILE PER LAMPADA DA TERRA / LEDS AVAILABLE FOR FLOOR LAMP
• LED 1x 12W - 22,4V-24,8V - 500mA - CRI Typ 95 - 1.717 Lm - 144 Lm/W - 180° - 3 Step MacAdam - 2700K or 3000K
LED DISPONIBILE PER LAMPADA A SOSPENSIONE GIG, APPLIQUE E PLAFONIERE / LEDS AVAILABLE FOR GIG HANGING LAMP, WALL LAMP AND CEILING LAMP
• LED 1x 8,4W - 22,4V-24,8V - 350mA - CRI Typ 95 - 1.202 Lm - 144 Lm/W - 180° - 3 Step MacAdam - 2700K or 3000K
LU1645.1L
LAMPADA DA TERRA / FLOOR LAMP
WITH DIMMER PUSH BUTTON
Glass 1 x Ø 30 cm - Cable 200 cm
1 x LED 12 W DIMM
16
30
182
LU1640.1L
LAMPADA DA TAVOLO / TABLE LAMP
WITH DIMMER PUSH BUTTON
Glass 1 x Ø 25 cm - Cable 200 cm
1 x LED 6 W DIMM
10
25
52
LU1650.1L
LAMPADA DA TAVOLO / TABLE LAMP
WITH DIMMER PUSH BUTTON
Glass 1 x Ø 25 cm - Cable 200 cm
1 x LED 6 W DIMM
10
25
50
LU1660.1L
LAMPADA DA TAVOLO / TABLE LAMP
WITH DIMMER PUSH BUTTON
Glass 1 x Ø 30 cm - Cable 200 cm
1 x LED 6 W DIMM
10
30
48
AP1641.1L
APPLIQUE / WALL LAMP
Glass 1 x Ø 25 cm
1 x LED 8,4 W DIMM
25
24
85
APGIG1641.1L
APPLIQUE / WALL LAMP
Glass 1 x Ø 30 cm
1 x LED 8,4 W DIMM
30
31
85
AP1651.1L
APPLIQUE / WALL LAMP
Glass 1 x Ø 25 cm
1 x LED 8,4 W DIMM
25
21
85
LU1655.1L
LAMPADA DA TERRA / FLOOR LAMP
WITH DIMMER PUSH BUTTON
Glass 1 x Ø 30 cm
1 x LED 12 W DIMM
16
30
180
LU1665.1L
LAMPADA DA TERRA / FLOOR LAMP
WITH DIMMER PUSH BUTTON
Glass 1 x Ø 35 cm
1 x LED 12 W DIMM
16
35
170
Cromo
Chrome
Cromo spazzolato
Brushed chrome
Nero opaco
Matt black
FINITURA DISPONIBILE PER: PIASTRE, BINARI E DISASSATORI / FINISH AVAILABLE FOR: PLATES, TRACKS AND SPACERS
Nichel nero satinato
Satin black nickel
Oro satinato
Satin gold
FINITURA DISPONIBILE PER: LAMPADA DA TAVOLO E LAMPADA DA TERRA / FINISH AVAILABLE FOR: TABLE LAMP AND FLOOR LAMP
Bianco opaco
Matt white
•
PERSONALIZZAZIONE LUNGHEZZA DEL CAVO SU RICHIESTA / CUSTOMISED CABLE LENGTH ON REQUEST
•
A RICHIESTA CON COMPONENTI UL / ON DEMAND WITH UL COMPONENTS
•
DISPONIBILE SU RICHIESTA CON DRIVER DALI / AVAILABLE ON REQUEST WITH DALI DRIVER
ON DEMAND / OPTIONAL FEATURES
DETTAGLI PRODOTTO
PRODUCT DETAILS
123
