TECHNICAL FEATURES | ELECTRIFIED BODY
Code
6988.CW
Type
Downlight 90° | Wall recessed 90°
Material
CW: Coral WaterOut® | waterproof
Weight
6.2 Kg
Mounting
Wall and ceiling recessed
IP rating
IP65
Insulation class
III
Control gear
Constant current electronic driver
(not included)
Cut out for plasterboard
1050 × 115 mm
Lamp type
LED
Vf: 3 VDC
Lamp wattage
1 × 1W - 350 mA | 1 × 2W - 500 mA
Luminous efficacy
1 × 75 lm - 3000K 350 mA
1 × 170 lm - 3000K 500 mA
Light distribution
Narrow beam 14°
Fitting
-
Light colour
White 3000K
Light hole
1000 × 45 mm
Voltage connection
By driver (optional)
CRI
>90
Emergency
-
Energy efficiency class
A++
Note
It is possible to cut the electrified body to obtain a light hole 400 mm minimum.
On request available dimmable PUSH or DALI, remote installation.
Other available light colours:
2700K,
4000K (on request).
OPTIONAL
ON/OFF
driver
cod. H8350
DALI dimmable
LED driver
cod. DRV0000029
PUSH dimmable
LED driver
cod. DRV0000026
Brick box
cod. BR6988LT
For further info and other available drivers please see page 474
BLADE
see page 267
OTHER AVAILABLE CODES
6988.27.CW
lens
14°
light colour
2700K
Blade IP65
1090
1040
75
80
45
105
min 400
434 |
