TECHNICAL FEATURES
Code
2998.AC
Type
Wall and ceiling recessed
Material
AC: AirCoral®
Absorption capacity*
22.8 m2
Weight
10.4 Kg
Mounting
Wall and ceiling mounting
IP rating
IP20
Insulation class
I
Control gear
Dimmable constant current driver
(included)
Cut out for plasterboard
460 × 460 mm
Lamp type
LED 500mA
Lamp wattage
2 × 6.5W
Luminous efficacy
2 × 930 lm - 3000K
Light distribution
Wide beam 120°
Fitting
-
Light colour
White 3000K
Light hole
-
Voltage connection
220-240V ∙ 50/60Hz
CRI
>90
Emergency
-
Energy efficiency class
A+
Note
Trailing-edge and leading-edge dimming
(20 - 100%).
Other available type of dimming:
1-10V,
DALI.
Other available light colours:
2700K,
4000K (on request).
Unleaf
OTHER AVAILABLE CODES
2998.27.AC
lens
120°
light colour
2700K
2998.40.AC
lens
120°
light colour
4000K (on request)
2998.AC 2 00 E _ _
lens
120°
dim. tech.
1
1-10V
DA
DALI
light colour
27
2700K
30
3000K
40
4000K (on request)
example of code
composition
2998.AC 2 00 E 30 DA
www.buzzi-buzzi.it | 293
Indoor Recessed
* The absorption capacity per m3 calculated by the American organization TCNA
(Tile Council of North America) is measured for an average room of 2.7 m in
height and therefore expressed in m2
