TECHNICAL FEATURES
Code
6488.00
Type
Wall-washer
Material
00: Coral®
Weight
1.4 Kg
Mounting
Wall and ceiling recessed
IP rating
IP40
Insulation class
III
Control gear
Remote constant current
electronic driver (not included)
Cut out for plasterboard
115 × 270 mm
Lamp type
LED
Vf: 3 VDC
Lamp wattage
1 × 1W - 350 mA | 1 × 2W - 500 mA
Luminous efficacy
1 × 75 lm - 3000K 350 mA
1 × 170 lm - 3000K 500 mA
Light distribution
Narrow beam 14°
Fitting
-
Light colour
White 3000K
Light hole
45 × 200 mm
Voltage connection
By driver (optional)
CRI
>90
Emergency
-
Energy efficiency class
A++
Note
Other available light colours:
2700K,
4000K (on request).
OPTIONAL
ON/OFF
driver
cod. H8350
cod. H8500.B | H8500.C | H8500.F
Trailing and leading
edge driver
cod. DRV0000087
DALI dimmable
LED driver
cod. DRV0000029
PUSH dimmable
LED driver
cod. DRV0000026
Brick box
cod. BR6488LT
For further info and other available drivers please see page 474
Phantom
PHANTOM IP44/IP65
see page 439
OTHER AVAILABLE CODES
6488.27.00
lens
14°
light colour
2700K
www.buzzi-buzzi.it | 273
Indoor Recessed
