TECHNICAL FEATURES
Code
6315.AC 4 R 40 E 98 WD
Type
Downlight 90°
Material
AC: AirCoral®
Absorption capacity*
2.82 m2
Weight
0.9 Kg
Mounting
Ceiling recessed
IP rating
IP20
Insulation class
III
Control gear
Remote ON/OFF driver** (not included)
Cut out for plasterboard
225 × 145 mm
Lamp type
LED 350 mA
Vf: 17 VDC
Lamp wattage
2 × 6W
Luminous efficacy
2 × 600 lm (from 1800K up to 3000K)
Light distribution
Wide beam 40°
Fitting
-
Light colour
Dimming range 1800/3000K
Light hole
160 × 80 mm
Voltage connection
By driver (optional)
CRI
>90
Emergency
-
Energy efficiency class
A++
Note
**Bilight Dim To Warm requires dimming:
amplitude (AM) dim to warm wide range
input voltage.
OPTIONAL
Amplitude DALI
dimmable LED driver
H8350DA.AM
Amplitude PUSH
dimmable LED driver
H8350PH.AM
Brick box
cod. BR6318LT
For further info and other available drivers please see page 474
Bilight Dim To Warm
210 |
