Dry
TECHNICAL FEATURES
Code
6113.Z.AC
6111.AC
6112.AC
Type
Wall recessed 90°
Wall recessed 45°
Wall recessed 90°
Material
AC: AirCoral®
AC: AirCoral®
AC: AirCoral®
Absorption capacity*
2.53 m2
2.53 m2
2.53 m2
Weight
1.5 Kg
1.5 Kg
1.5 Kg
Mounting
Wall recessed
Wall recessed
Wall recessed
IP rating
IP40
IP40
IP40
Insulation class
III
III
III
Control gear
ON/OFF driver (included)
Dimmable electronic
transformer (included)
Dimmable electronic
transformer (included)
Cut out for plasterboard
195 × 185 mm
195 × 185 mm
195 × 185 mm
Lamp type
LED 350 mA
QR CB 51
QR CB 51
Vf: 11.5 VDC
Lamp wattage
1 × 9W
1 × 50W max
1 × 50W max
Luminous efficacy
1 × 1125 lm - 3000K
-
-
Light distribution
Wide beam 40°
-
-
Fitting
-
GU5.3
GU5.3
Light colour
White 3000K
-
-
Light hole
80 × 80 mm
80 × 80 mm
80 × 80 mm
Voltage connection
220-240V · 50/60Hz
220-240V / 12V ·
50/60Hz
220-240V / 12V ·
50/60Hz
CRI
>90
-
-
Emergency
-
-
-
Energy efficiency class
A++
A
A
Note
Extra white satin glass fixed
by clip on wall level.
On request available
dimmable PUSH or DALI.
Other available light colours:
2700K,
4000K (on request).
Extra white satin glass fixed
by clip on wall level.
Extra white satin glass fixed
by clip on wall level.
OPTIONAL
Kit LED dimmable
-
cod. 0008KIT
cod. 0008KIT
For further info and other available drivers please see page 474
OTHER AVAILABLE CODES
6113.Z.27.AC
lens
40°
light colour
2700K
6113.Z.40.AC
lens
40°
light colour
4000K (on request)
www.buzzi-buzzi.it | 191
Indoor Recessed
* The absorption capacity per m3 calculated by the American organization TCNA
(Tile Council of North America) is measured for an average room of 2.7 m in
height and therefore expressed in m2
