OTHER AVAILABLE CODES
184_.AC 4 R _ E _ WD
light colour
27
2700K
30
3000K
40
4000K (on request)
lens
22
22°
50
50°
finishing
6
black
8
white
emergency
184_.AC 4 R _ E _ ND
light colour
27
2700K
30
3000K
40
4000K (on request)
lens
22
22°
50
50°
finishing
7
black
9
white
example of code
composition
1846.AC 4 R 22 E 30 WD
TECHNICAL FEATURES
Code
184X.AC XX
184X.AC XX emergency
Type
Tiltable downlight ± 360° / ± 35°
Tiltable downlight ± 360° / ± 35°
Material
AC: AirCoral®
AC: AirCoral®
Absorption capacity*
1.39 m2
1.39 m2
Finishing
Black | White
Black | White
Weight
0.8 Kg
0.8 Kg
Mounting
Wall and ceiling recessed
Wall and ceiling recessed
IP rating
IP40
IP40
Insulation class
III
III
Control gear
Remote constant current
electronic driver (not included)
Remote constant current electronic driver
(not included), inverter (included)
Cut out for plasterboard
135 × 110 mm
135 × 110 mm
Lamp type
LED 500 mA
LED 500 mA
Vf: 11.5 VDC
Vf: 11.5 VDC
Lamp wattage
1 × 6W
1 × 6W
Luminous efficacy
1 × 600 lm - 3000K
1 × 600 lm - 3000K
Light distribution
Beam 22°
Beam 50° (on request)
Beam 22°
Beam 50° (on request)
Fitting
-
Light colour
White 3000K
White 2700K | 4000K (on request)
White 3000K
White 2700K | 4000K (on request)
Light hole
Ø 23 mm
Ø 23 mm
Voltage connection
By driver (optional)
220-240V · 50/60Hz
CRI
>90
>90
Emergency
-
1 hour
Energy efficiency class
A++
A++
Note
-
-
OPTIONAL
ON/OFF
driver
cod. H8500.E
cod. H8500.E
Trailing and leading
edge driver
cod. DRV0000168
cod. DRV0000168
DALI dimmable
LED driver
cod. DRV0000029
cod. DRV0000029
PUSH dimmable
LED driver
cod. DRV0000026
cod. DRV0000026
PUSH/1-10V/DALI
dimmable LED driver
cod. DRV0000093
cod. DRV0000093
For further info and other available drivers please see page 474
Inzeta
www.buzzi-buzzi.it | 165
Indoor Recessed
* The absorption capacity per m3 calculated by the American organization TCNA
(Tile Council of North America) is measured for an average room of 2.7 m in
height and therefore expressed in m2
