TECHNICAL FEATURES
Code
3123.Z.00
3121
3122
Type
Downlight 90°
Downlight 90°
Downlight 90°
Material
00: Coral®
00: Coral®
00: Coral®
Weight
0.8 Kg
0.7 Kg
0.7 Kg
Mounting
Ceiling recessed
Ceiling recessed
Ceiling recessed
IP rating
IP20
IP20
IP20
Insulation class
III
III
I
Control gear
Remote constant current
electronic driver (not
included)
Electronic transformer
(not included)
-
Dimensions
A: 80 mm; B: 100 mm
A: 70 mm; B: 90 mm
A: 80 mm; B: 100 mm
Cut out for plasterboard
150 × 150 mm
150 × 150 mm
150 × 150 mm
Lamp type
LED 500 mA
QR CB 51 LED (optional)
QPAR 16 LED (optional)
Vf: 18 VDC
Lamp wattage
1 × 9W
50W max
50W max
Luminous efficacy
1 × 1125 lm - 3000K
-
-
Light distribution
Wide beam 40°
-
-
Fitting
-
GU5.3
GU10
Light colour
White 3000K
-
-
Light hole
Ø 50 mm
Ø 50 mm
Ø 50 mm
Voltage connection
By driver (optional)
By driver (optional)
220-240V · 50/60Hz
CRI
>90
-
-
Emergency
-
-
-
Energy efficiency class
A++
A
A
Note
Other available light colours:
2700K,
4000K.
-
-
OPTIONAL
ON/OFF
driver
cod. H8500.E
-
-
Trailing and leading
edge driver
cod. DRV0000163
cod. H8060.LED
-
DALI dimmable
LED driver
cod. DRV0000029
-
-
PUSH dimmable
LED driver
cod. DRV0000026
-
-
PUSH/1-10V/DALI
dimmable LED driver
cod. DRV0000093
-
-
Kit LED dimmable
-
cod. 0008KIT
cod. 0009KIT
Brick box
cod. BR3123LT
cod. BR3121LT
cod. BR3122LT
For further info and other available drivers please see page 474
Basic Round
OTHER AVAILABLE CODES
3123.Z.27.00
lens
40°
light colour
2700K
3123.Z.40.00
lens
40°
light colour
4000K
www.buzzi-buzzi.it | 155
Indoor Recessed
