H2NOT
Un’illuminazione che regala fascino ad ambienti che hanno bisogno di un
grado di protezione contro l’acqua: H2NOT è un apparecchio in alluminio
da esterni ad incasso per installazione a soffitto e a parete, ed è l’alleato
perfetto per garantire la giusta luminosità di SPA, wellness club o spazi
privati dove l’acqua e la luce sono le vere protagoniste. Le caratteristiche
di impermeabilità all’acqua unite alla verniciatura a polveri ad alta
resistenza lo rendono uno strumento ideale per gli ambienti umidi.
An illumination capable of giving the right charm to environments which
need protection from water: H2NOT is a recessed outdoor luminaire
in aluminium installable on ceilings and walls and available with white
finishings. It is the perfect ally to guarantee the correct lighting in
SPAs, wellness clubs or private spaces where water and light are the
real protagonists. Its waterproof characteristics, combined with its
resistance dust painting, make H2NOT ideal for moist places.
TECHNICAL FEATURES
Code
2041 XX
2044 XX
Type
Downlight 90°
Wall recessed 90°
Downlight 90°
Wall recessed 90°
Material
Aluminum
Aluminum
Finishing
White
White
Weight
0.25 Kg
0.25 Kg
Mounting
Wall and ceiling recessed
Wall and ceiling recessed
IP rating
IP65
IP65
Insulation class
III
III
Control gear
Constant current electronic
driver (not included)
Remote dimmable constant
current electronic driver**
(not included)
Cut out for plasterboard
Ø 75 mm
Ø 75 mm
Lamp type
LED 500 mA
LED 350 mA
Vf: 18 VDC
Vf: 17 VDC
Lamp wattage
1 x 9W
1 x 6W
Luminous efficacy
1125 lm - 3000K
600 lm
(from 1800K up to 3000K)
Light distribution
Wide beam 40°
Wide beam 40°
Fitting
-
-
Light colour
White 3000K
White 2700K | 4000K
(on request)
Dimming range 1800/3000K
Voltage connection
By driver (optional)
By driver (optional)
CRI
>90
95
Emergency
-
-
Note
On request available
dimmable PUSH or DALI.
On request available
dimmable PUSH or DALI,
remote installation.
**H2NOT code 2044 XX
requires dimming: amplitude
(AM) IEEE1789-2015 dim
to warm wide range input
voltage.
CODE COMPOSITION
2041 WH 2 R 40 E _ WD
light colour
27
2700K
30
3000K
40
4000K
2044 WH 4 R 40 E 98 WD
example of code composition
2041 WH 2 R 40 E 30 WD
OPTIONAL ACCESSORIES
product code
optional code
description
info
2041 XX
H8500.E
Constant current
electronic driver
Suitable for n°2 code 2041 XX - 500 mA
H8500.B
Constant current
electronic driver
Suitable for n°1 code 2041 XX - 500 mA
2044 XX
H8350DA.AM
Dimming:
amplitude (AM) DALI
Suitable for n°2 code 2044 XX
H8350PH.AM
Dimming:
amplitude (AM) PUSH
Suitable for n°2 code 2044 XX
matt white
INCASSO CON GRADO DI PROTEZIONE IP65.
RECESSED WITH IP65 PROTECTION RATING.
288 |
www.buzzi-buzzi.it | 289
Outdoor Recessed stand alone
