THE DARK
The Dark è una lampada a sospensione lineare per ambienti interni.
Il suo design ne enfatizza il nome proponendosi per essere un punto
luce completamente nero grazie alla presenza di uno schermo
fumè, che mette in evidenza la sua capacità luminosa solo quando è
acceso. Disponibile anche con schermo satinato. È una lampada dalla
forma essenziale e minimale che crea una luce diffusa e omogenea
nello spazio.
È disponibile una versione con driver incluso nel rosone e una versione
con rosone a scomparsa in battuta con driver remoto.
The Dark is a linear pendant light for interiors. Its design epitomises
its name proposing itself as a completely black light point thanks
to a smoked shade which shows off its light capacity only when it is
switched on. Also available with satin-finished shade. It is a light with a
clean-cut minimal shape which creates a diffused and homogeneous
light in the space.
It is available in a version with driver included in the ceiling-rose and a
version with recessed ceiling-rose with remote driver.
CODE COMPOSITION
1140 BL 4 S 00 E _ ND
light colour
27
2700K
30
3000K
40
4000K
1141 BL 4 S 00 E _ ND
light colour
27
2700K
30
3000K
40
4000K
example of code composition
1140 BL 4 S 00 E 30 ND
TECHNICAL FEATURES
Code
1140 XX (fig. A)
1141 XX (fig. B)
Type
Suspension lamp
Suspension lamp
Material
Aluminum
Aluminum
Finishing
Black
Black
Weight
2 Kg
2 Kg
Mounting
Ceiling mounting
Ceiling mounting
IP rating
IP40
IP40
Insulation class
III
III
Control gear
Constant voltage LED driver
on board (included)
Constant voltage LED driver,
remote installation (included)
Cut out for plasterboard
-
Ø 55 mm
Lamp type
LED
LED
Lamp wattage
1 x 25W
1 x 25W
Luminous efficacy
1800 lm
1800 lm
Light distribution
Opal diffused screen fumè
Opal diffused screen fumè
Fitting
-
-
Light colour
White 3000K
White 2700K | 4000K
(on request)
White 3000K
White 2700K | 4000K
(on request)
Voltage connection
220-240V · 50/60Hz
220-240V · 50/60Hz
CRI
>90
>90
Emergency
-
-
Note
Black ceiling box
with driver on board.
Black silicone cable
(L max 2 m).
Black recessed canopy
with remote driver.
Black silicone cable
(L max 2 m).
matt black
SCHERMO FUMÈ PER UN LOOK TOTAL BLACK
QUANDO È SPENTO.
FUMÈ SHADE FOR A TOTAL BLACK LOOK
WHEN TURNED OFF.
A
B
OPTIONAL ACCESSORIES
product code
optional code
description
info
1140 XX / 1141 XX
VTR0000019
Opal white diffused screen
-
30
850
45
max2000
65
max2000
www.buzzi-buzzi.it | 263
