THE TUBE
CODE COMPOSITION
1131 _ 4 S 00 E _ ND
light colour
27
2700K
30
3000K
finishing
WH
white
BL
black
CP
chromed
A1
champagne
A2
rose gold
1132 _ 4 S 00 E _ ND
light colour
27
2700K
30
3000K
finishing
WH
white
BL
black
CP
chromed
A1
champagne
A2
rose gold
example of code composition
1131 WH 4 S 00 E 27 ND
The Tube è una lampada a sospensione dal design minimale, il suo
diametro di soli 15 mm la rendono estremamente essenziale, discreta,
elegante nelle forme. Ha un output luminoso in grado di valorizzare ogni
dettaglio, disponibile in diverse colorazioni.
È disponibile una versione con driver incluso nel rosone e una versione
con rosone a scomparsa in battuta con driver remoto.
The Tube is a pendant light with a minimal design. Its diameter of only
15 mm makes it extremely clean-cut, discrete and elegant in shape.
It has a light output that can enhance every detail and is available in
different colours.
It is available in a version with driver included in the ceiling-rose and a
version with recessed ceiling-rose with remote driver.
TECHNICAL FEATURES
Code
1131 XX (fig. A)
1132 XX (fig. B)
Type
Suspension lamp
Suspension lamp
Material
Aluminum
Aluminum
Finishing
White | Black
Champagne | Rose Gold
White | Black
Champagne | Rose Gold
Weight
0.8 Kg
0.8 Kg
Mounting
Ceiling mounting
Ceiling mounting
IP rating
IP40
IP40
Insulation class
III
III
Control gear
Electronic driver
on board (included)
Electronic driver, remote
installation (included)
Cut out for plasterboard
-
Ø 45 mm
Lamp type
LED
LED
Lamp wattage
1 x 4.5W
1 x 4.5W
Luminous efficacy
360 lm - 3000K
360 lm - 3000K
Light distribution
Narrow beam
Narrow beam
Fitting
-
-
Light colour
White 3000K
White 2700K (on request)
White 3000K
White 2700K (on request)
Voltage connection
220-240V · 50/60Hz
220-240V · 50/60Hz
CRI
>90
>90
Emergency
-
-
Note
Black ceiling box
with driver on board.
Black silicone cable (L 1.5 m).
On request different lenght.
Black recessed canopy
with remote driver.
Black silicone cable (L 1.5 m).
On request different lenght.
A
B
500
Ø15
Ø60
500
Ø15
55
pending
matt white
matt black
champagne
rose gold
1.50 m
1.50 m
chromed
www.buzzi-buzzi.it | 259
Indoor Suspended stand alone
258 |
