Q1
Proiettore ad alte performance in metallo verniciato a polvere: Q1 è un
apparecchio per interni adatto per installazione a soffitto e a parete.
Garantisce il minimo impatto visivo, è completamente orientabile a
360° in orizzontale e in verticale e disponibile in più varianti ottiche.
A high-performance, metallic dust-painted projector: Q1 is an indoor
luminaire installable on ceilings, walls. It guarantees a minimal visual
impact and is completely orientable up to 360° both horizontally and
vertically. It is also available with different lens.
CODE COMPOSITION
1012 _ 3 S _ E _ ND
light colour
27
2700K
30
3000K
40
4000K
lens
12
12°
24
24°
38
38°
finishing
WH
white
BL
black
example of code composition
1012 WH 3 S 24 E 30 ND
TECHNICAL FEATURES
Code
1012 XX
Type
Projector ± 360° / ± 90°
Material
Aluminum
Finishing
White | Black
Weight
0.8 Kg
Mounting
Wall and ceiling
IP rating
IP40
Insulation class
III
Control gear
Constant current electronic driver on board (included)
Lamp type
LED 350 mA
Lamp wattage
1 x 12W
Luminous efficacy
1550 lm - 3000K
Light distribution
Beam 24°
Beam 12° | 38° (on request)
Fitting
-
Light colour
White 3000K
White 2700K | 4000K (on request)
Voltage connection
220-240V · 50/60Hz
CRI
>90
Emergency
On request
Note
On request available dimmable PUSH or DALI.
ALTA POTENZA CON DRIVER INCLUSO.
HIGH POWER WITH DRIVER INCLUDED.
matt white
matt black
pending
252 |
www.buzzi-buzzi.it | 253
Indoor Surface stand alone
