Xtra Compact (XCP)
Esempi installativi delle cassette di derivazione
Non tutte le cassette possono essere installate in ogni posizione.
Nelle figure seguenti è possibile controllare dove possono essere installate le varie cassette di derivazione, su elementi con predisposizioni standard.
T1/T2/T3: tipo di cassetta di derivazione
M: cassetta di derivazione in metallo
P: cassetta di derivazione in vetroresina
n Informazioni tecniche
Nota:
X = E/T/M/MT
Y = EB/M/MT
CASSETTE DI DERIVAZIONE E INTERRUTTORI ASSOCIABILI
Caratteristiche cassette di derivazione
Interruttori associabili
Cassette di
derivazione
Materiale
Tipo
In (A)
Tipo coperchio Taglia
PU
Codici interruttori
50485231
fibra di
vetro
2
63
Incernierato
M1
Magnetotermico
(senza differenziale)
T713E16/25/40/63 T713B16/25/40/63 T713N16/25/40/63
T714E16/25/40/63 T714B16/25/40/63 T714N16/25/40/63
Solo magnetico
T7MP13E16/25/50/63 T7MP13B16/25/50/63
50485232
fibra di
vetro
2
160
Incernierato
M1
Magnetotermico
(senza differenziale)
T713E80/100/125/160 T713B80/100/125/160 T713N80/100/125/160
T714E80/100/125/160 T714B80/100/125/160 T714N80/100/125/160
50485233
fibra di
vetro
3
250
Incernierato
M2
Magnetotermico
(senza differenziale)
T723B100/160/200/250 T723F100/160/200/250 T723H100/160/200/250
T724B100/160/200/250 T724F100/160/200/250 T724H100/160/200/250
Solo magnetico
T7MP23F100/160/200/250 T7MP23H100/160/200/250
Elettronico
T723B40/100/160/250X T723F40/100/160/250X T723H40/100/160/250X
T724B40/100/160/250X T724F40/100/160/250X T724H40/100/160/250X
50481721
metallo
1
63/125/
160
Incernierato
M1
Magnetotermico
(senza differenziale)
T713E16/25/40/63/80/100/125/160 T713B16/25/40/63/80/100/125/160 T713N16/25/40/63/80/100/125/160
T714E16/25/40/63/80/100/125/160 T714B16/25/40/63/80/100/125/160 T714N16/25/40/63/80/100/125/160
Solo magnetico
T7MP13E16/25/50/63 T7MP13B16/25/50/63
50481731
metallo
1
63/125/
160
Rimovibile
M1
Magnetotermico
(senza differenziale)
T713E16/25/40/63/80/100/125/160 T713B16/25/40/63/80/100/125/160 T713N16/25/40/63/80/100/125/160
T714E16/25/40/63/80/100/125/160 T714B16/25/40/63/80/100/125/160 T714N16/25/40/63/80/100/125/160
Solo magnetico
T7MP13E16/25/50/63 T7MP13B16/25/50/63
50481722
metallo
2
250A
Incernierato
M2
Magnetotermico
(senza differenziale)
T723B100/160/200/250 T723F100/160/200/250 T723H100/160/200/250
T724B100/160/200/250 T724F100/160/200/250 T724H100/160/200/250
Solo magnetico
T7MP23F100/160/200/250 T7MP23H100/160/200/250
Elettronico
T723B40/100/160/250X T723F40/100/160/250X T723H40/100/160/250X
T724B40/100/160/250X T724F40/100/160/250X T724H40/100/160/250X
50481732
metallo
2
250A
Rimovibile
M2
Magnetotermico
(senza differenziale)
T723B100/160/200/250 T723F100/160/200/250 T723H100/160/200/250
T724B100/160/200/250 T724F100/160/200/250 T724H100/160/200/250
Solo magnetico
T7MP23F100/160/200/250 T7MP23H100/160/200/250
Elettronico
T723B40/100/160/250X T723F40/100/160/250X T723H40/100/160/250X
T724B40/100/160/250X T724F40/100/160/250X T724H40/100/160/250X
50481723
metallo
3
400/630
Incernierato
M4
Magnetotermico
T743F250/320/400/500/630 T743N250/320/400/500/630 T743L250/320/400/500/630
T744F250/320/400/500/630 T744N250/320/400/500/630 T744L250/320/400/500/630
Solo magnetico
T743F400/500/630MP T743H400/500/630MP
Elettronico
T743F250/320/400/500/630Y T743N250/320/400/500/630Y T743L250/320/400/500/630Y
T744F250/320/400/500/630Y T744N250/320/400/500/630Y T744L250/320/400/500/630Y
50481733
metallo
3
400/630
Rimovibile
M4
Magnetotermico
T743F250/320/400/500/630 T743N250/320/400/500/630 T743L250/320/400/500/630
T744F250/320/400/500/630 T744N250/320/400/500/630 T744L250/320/400/500/630
Solo magnetico
T743F400/500/630MP T743H400/500/630MP
Elettronico
T743F250/320/400/500/630Y T743N250/320/400/500/630Y T743L250/320/400/500/630Y
T744F250/320/400/500/630Y T744N250/320/400/500/630Y T744L250/320/400/500/630Y
