SUGGESTED OPTIONAL ACCESSORIES
BLANCO UNIT WITH ANDANO-IF
ANDANO-IF STAINLESS STEEL
— Unique composition of optical and functional elements
— The harmonious interplay between the radii and surface design
creates a modern appeal
— High quality features consisting of a covered C-overflow and InFino
drain system – gracefully integrated and easy-care
— Large bowl capacity and fully utilisable base
— Elegant IF flat-rim for flushmount and for installation from above
Flat
rim IF
CABINET SIZE MM
ANDANO-IF
340/180-IF
340/180-IF
500-IF
Bowl right
Bowl left
satin polish
522 973
522 975
522 965
Bowl depth
190/130 mm
190/130 mm
190 mm
BOWL RADIUS
PLANNING NOTE
Note: Installing a kitchen mixer
tap, drain remote control or soap
dispenser in laminate worktops
requires a flexible sealing tape.
Note: Installing a kitchen mixer
tap, drain remote control or soap
dispenser in laminate worktops
requires a flexible sealing tape.
Note: Installing a kitchen mixer
tap, drain remote control or soap
dispenser in laminate worktops
requires a flexible sealing tape.
Please order drain connections
for combinations of two individual
bowls separately.
SCOPE OF SUPPLY
InFino drain system without
remote control
waste kit with space-saving pipe,
2 x 3 ½‘‘ InFino basket strainer,
fixing kit
waste kit with space-saving pipe,
2 x 3 ½‘‘ InFino basket strainer,
fixing kit
waste kit with space-saving pipe,
3 ½‘‘ InFino basket strainer,
fixing kit
Silver-coloured safety glass
cutting board
227 697
Multifunctional stainless
steel colander
227 692
Multifunctional wire basket
223 297
SONEA-S Flexo
see page 358
FLEXON II 60/3
see page 430
600 mm
Stainless steel
bowls
3
174
You will find detailed dimensions and drawings with cut-out details on the Internet at www.blanco.com.
Information on Regulation (EG) 1907/2006 (REACH) can be found in the service chapter.
