104
105
beneito-faure.com
beneito-faure.com
VIDEO
custom system
27mm x L
Opal (110º)
White (9003)
Black (9005)
1
2
Equipment
455x47x28mm
2m
5 YEARS
WARRANTY
50.000
HOURS
PF
>0,9
CRI
≥95
IP
20
2m
Max
PUSH
230
VAC
i
Custom RAL
C
Flex (Fine 61)
RoHS
Dau E
Installation
Lumens
Recessed and Surface / Pendant
Technical Information
On / O�
Dali
Push
Casambi
16
1
2
3
5
Code:
Colour
Driver
CCT (lm/W)
Size
Code / Di�user (Angle)
*Create your code acording to your preferences. CCT 2.700-5.500K only works with driver 5 Casambi and 7 Tuya.
Tuya
7
i
Consult delivery terms and conditions.
Power
Dau
15
Material
Aluminium
PCB
Control accessories pages 294-307.
2.700K (100 lm/W)
3.000K (105 lm/W)
1.170mm
1.420mm
2
3
3
4
1.720mm
1.970mm
5
6
4.000K (111 lm/W)
5.000K (114 lm/W)
4
5
RGB-W (100 lm/W)
8
2.700-5.500K (105 lm/W)
9
*Finished luminaire. Includes power supply, suspension kit,
ceiling suspension, power cable and end caps.
*Finished luminaire. Includes power supply,
spring clips, power cable and end caps.
1.800 lm - 3.420 lm
18W / 23W / 26W / 30W
Dau E
Dau
25mm
25mm
35mm
25mm
38mm
Opal (110º)
Dau E
Dau
CUSTOM SYSTEM
