luminaires
Urban
RoHS
5 YEARS
WARRANTY
50.000
HOURS
PF
>0,9
CRI
≥95
UGR
<19
beneito-faure.com
IP
40
Code
Installation
Lumens
Material
Surface / Pendant
5.152 lm - 14.008 lm
Aluminium
Technical Information
White (9003)
Black (9005)
On / O�
Dali
Push
Casambi
2.700K (112 lm/W) - 40W/m
3.000K (128 lm/W) - 40W/m
4.000K (136 lm/W) - 40W/m
5.000K (136 lm/W) - 40W/m
1.130mm
1.410mm
UGR (78º)
6
4
2
3
4
5
3
4
1
2
3
5
1
2
6
Code:
Colour
Driver
CCT (lm/W) - Power/m
Size
Di�user (Angle)
Code
1.690mm
5
Opal (112º)
5
1.970mm
6
2.530mm
7
58mm
68mm
Driver
Gray (9006)
3
*Create your code acording to your preferences. CCT 2.700-5.500K only works with driver 5 Casambi and 7 Tuya.
Accessories
40722
40721
40790 (2m)
40882
40881
40780
End caps
40550
40851
40220
Joint 180º
Joint 90º
Wall bracket
Base 3x0,75 (2,5m)
Suspension Kit
Ceiling suspension
3,37m
Max
40723
Ø60x28mm
40852
40853
40992
40991
Base 5x0,5 (2,5m)
Ø60x28mm
40883
40993
PUSH
2.700-5.500K (105 lm/W) - 40W/m
9
Tuya
7
40669
Trimless
230
VAC
Matt Gold
Corten
4
6
Copper
7
i
i
i
Custom RAL
i
i
Consult delivery terms and conditions.
Power
46W / 57W / 69W / 80W / 103W
Personal training room, Collbató (Spain).
C
PCB
Rigid
Electrolytic Plating
i
Control accessories pages 282-289.
Accessories pages 158-159.
