WWW.BEL-LIGHTING.COM
66
230V
G9 & Led 6W
Paco
Body made in profile aluminum or stainless steel
Screws in stainless steel
Safety sandblasted plexiglass
Led 230V CRI>90 3SDCM 54.000hrs L80 B10
Degree of protection IP65 - IK07
DESCRIPTION
Painted in RAL colors
Other anodized color
Other material: brass / copper / ...
Other led color: 2700K / 4000K
ON REQUEST
∅100
45
code: 909SA. XX . XX
led bulb
color
G9
G9 LED (max. diameter 32mm / height 65mm)
W6
Led 6W 230V - 3000K
LED / BULB
02A
Anodized black
04
Brushed stainless steel
32
Anodized aluminum
COLOR
Led 6W 230V 2700K / 4000K = on request
Led 4W 230V = on request
DIMMABLE
2700 K
Typical luminous flux (lm)
6W
470
3000 K
efcacity
95lm/W
max.
460
Typical luminous flux (lm)
480
4000 K
4W
320
315
340
0,5
IP65
230V
IK07
