32
∅ min: 32mm
min: 30mm
350mA
1,1W - 3,2W
Recessed box - Pop 12 ref: X012
Led driver AC/CC 350mA
Led driver DC/CC (12-36VDC/350mA)
IP68 connection - Connex 4 ref: X083
ACCESSORIES
Body made in solid aluminum
Screws in stainless steel
Safety sandblasted plexiglass
Led 350mA CRI>90 3SDCM 85.000hrs L80 B10
Provided with 20cm wire (2x 0,5mm²)
Degree of protection IP65 - IK06
DESCRIPTION
Painted in RAL colors
Other anodized color
Other material: brass / copper / stainless steel
Other led color: 3000K / 5000K
ON REQUEST
0,5
IP65
350mA
IK06
0,20
Faki R
Faki K
2700 K
Typical luminous flux (lm)
1,1W
3,2W
115
395
370
355
3000 K
410
5000 K
145
4000 K
efcacity
132lm/W
max.
125
135
Typical luminous flux (lm)
code: 8082R. XXX . XX
color
led
code: 8082K. XXX . XX
color
led
D10
1,1W - 4000K - 70°
D30
3,2W - 4000K - 70°
W10
1,1W - 2700K - 70°
W30
3,2W - 2700K - 70°
LED
00
Natural brushed aluminum
01
White
02A
Anodized black
32
Anodized aluminum
33
Anodized bronze
39
Grey
48
Dark grey (RAL 7016 structured)
COLOR
3000K / 5000K = on request
DIMMABLE
DIMMABLE
18
∅ 40
3 mm (coverplate)
∅ 32mm
min: 30mm
2 x 0,5mm²
18
40 x 40
∅ 32mm
min: 30mm
2 x 0,5mm²
3 mm (coverplate)
