230V
6W -12W
Cylo 1
Body made in solid aluminum
Screws in stainless steel
Safety sandblasted plexiglass
Led 230V CRI>90 3SDCM 54.000hrs L80 B10
Degree of protection IP65 - IK07
DESCRIPTION
Painted in RAL colors
Other led color: 4000K
Led 3,2W or 6W 350mA: 2700K / 3000K / 4000K / 5000K
ON REQUEST
0,5
IP65
230V
IK07
0,65
Typical luminous flux (lm)
6W
460
2700 K
efcacity
80lm/W
Typical luminous flux (lm)
max.
470
3000 K
480
4000 K
272
6W 230V - 2700K
302
6W 230V - 3000K
LED
01
White
02A
Anodized black
32
Anodized aluminum
33
Anodized bronze
34
Anodized matt gold
35
Anodized green
36
Anodized burgundy
COLOR
6W 230V 4000K = on request
4W 230V 2700K / 3000K / 4000K = on request
3,2W or 6W 350mA 2700K / 3000K / 4000K / 5000K = on request
code: 346. XXX . XX
led
color
• Please refer to the information pages for the specific characteristics of anodised finishes.
• Veuillez vous référer aux pages d’informations pour les caractéristiques particulières des surfaces anodisées.
• Raadpleeg de informatiepagina’s voor specifieke kenmerken van geanodiseerde oppervlakken.
• Bitte beachten Sie die Informationsseiten zu den besonderen Eigenschaften eloxierter Oberflächen.
• Παρακαλώ συμβουλευτείτε τις σελίδες πληροφοριών για τα συγκεκριμένα χαρακτηριστικά των ανοδειώσεων.
60
100
∅ 60
27
105
DIMMABLE
TRIAC
