Recessed luminaires for walls and staircases
We have a range of perfectly matched accessories available for the various
installation situations. During the planning phase, please pay attention to the
instructions for use for the installation housings available on our website.
Unshielded light
Installation housing
Plaster frame
LED
Controllable
A
B
C
Type A
Type B
Type C
Type D
33 109 4.8 W
330 lm
on/off
170
70 65
10 424
13 519
10 024
13 503
33 165 7.0 W
515 lm
on/off
260
70 65
10 425
13 520
10 025
13 504
33 168 9.0 W
700 lm
on/off
320
70 65
10 426
13 521
10 026
13 505
33 155 15.0 W
1130 lm
DALI
330 125 90
10 436
13 522
10 036
13 506
33 157 19.0 W
1560 lm
DALI
420 125 90
10 437
13 523
10 037
13 507
33 159 22.6 W
1980 lm
DALI
520 125 90
10 438
13 524
10 038
13 508
Unshielded light as location luminaires
Installation housing
Plaster frame
LED
Controllable
A
B
C
Type A
Type B
Type C
Type D
33 107 2.7 W
170 lm
on/off
170
70 65
10 424
13 519
10 024
13 503
33 163 3.8 W
240 lm
on/off
260
70 65
10 425
13 520
10 025
13 504
33 166 4.5 W
335 lm
on/off
320
70 65
10 426
13 521
10 026
13 505
33 154 7.0 W
595 lm
on/off
330 125 90
10 436
13 522
10 036
13 506
33 156 9.8 W
820 lm
on/off
420 125 90
10 437
13 523
10 037
13 507
33 158 11.8 W
1060 lm
on/off
520 125 90
10 438
13 524
10 038
13 508
Shielded light as location luminaires
Installation housing
Plaster frame
LED
Controllable
A
B
C
Type A
Type B
Type C
Type D
33 017 2.7 W
30 lm
on/off
170
70 65
10 424
13 519
10 024
13 503
33 018 3.8 W
45 lm
on/off
260
70 65
10 425
13 520
10 025
13 504
33 019 4.1 W
40 lm
on/off
320
70 65
10 426
13 521
10 026
13 505
33 050 7.0 W
50 lm
on/off
330 125 90
10 436
13 522
10 036
13 506
33 051 9.8 W
110 lm
on/off
420 125 90
10 437
13 523
10 037
13 507
33 052 11.8 W
130 lm
on/off
520 125 90
10 438
13 524
10 038
13 508
Unshielded
Location luminaire unshielded
Shielded
You can find an overview of the various
installation options on Page 39
You can find an overview of the various
installation options on Page 39
Recessed luminaires for walls and staircases
for flush or surface-mounted installation
Unshielded light
Protection class IP 65
Cast aluminium · Safety glass
on/off or DALI controllable power supply units · BEGA Thermal Management ®
LED colour temperature: 3000 K – article number + K3 or 4000 K – article number + K4
Luminaire colour · BEGA Tricoat ®
Graphite – article number
Silver
– article number + A
20-year availability guarantee for replacement parts and LED modules
Recessed luminaires for walls and staircases
for flush or surface-mounted installation
Shielded light
Protection class IP 65
Cast aluminium · Safety glass
On/off power supply units · BEGA Thermal Management ®
LED colour temperature: 3000 K – article number + K3 or 4000 K – article number + K4
Luminaire colour · BEGA Unidure®
Graphite – article number
Silver
– article number + A
20-year availability guarantee for replacement parts and LED modules
• New in the range
Emergency lighting luminaires with a single emergency
lighting battery of this series can be found on Page 263
and at bega.com/emergency-lighting
Supplement
Page 8
Illumination
diagrams
Supplement
Page 8
Illumination
diagrams
46
